—16—
4. TROUBLESHOOTING GUIDE
4.1 OUTSIDE DIMENSIONS
unit: mm(inch)
10. Slide the unit into the cabinet.(See Fig. 26)
CAUTION: For security purpose, reinstall screws (Type
A) at the cabinet's sides.
11. Cut the Foam-Strip to the proper length and insert
between the upper and lower window sash.
(See Fig. 27)
12. Attach the window Locking Bracket with a type C
screw. (See Fig. 28)
13. Attach the front grille to the cabinet by inserting the
tabs on the grille into the tabs on the front of the
cabinet. Push the grille in until it snaps into
place.(See Fig. 29)
14. Lift the inlet grille and secure it with a type A screw
through the front grille.(See Fig. 30)
Figure 26
Figure 27
Figure 28
Figure 31
Figure 30
Figure 29
To Next Page
