—34—
7. REPLACEMENT PARTS LIST
• MODEL: KP08A10
R: Service Parts
N: Non Service Parts
A FRONT GRILLE ASSY 3531A20189A 1 R
1 FRONT GRILLE 3530A20036A 1 R
2 INLET GRILLE 3530A20080A 1 R
3 AIR FILTER ASSY 5231A20006A 1 R
4 LOUVER,HORIZONTAL 4758A20019A 1 R
5 LOUVER,VERTICAL 4758A20040A 1 R
6 LOUVER,VERTICAL 4758A20040B 1 R
7 CABINET ASSEMBLY,SINGLE 3091AR2317H 1 R
B COMP& ACCESSORY ASSY
8 ANTI-VIBRATION BUSH 4830AR4335A 3 R
9 COMPRESSOR 5416A90007A 1 R
10 BRACKET,WASHER 4810AR4155B 3 N
11 67301700 HEXAGON NUTS 1NHA0801206 3 N
12 67301502 GASKET 4986A30001A 1 R
13 O.L.P 6750A30001N 1 R
14 67301202 TERMINAL COVER 3550A30048A 1 R
15 67301100 GASKET NUT 4H01058A 1 R
16 67301000 NUT,TERMINAL COVER 4H00947A 1 R
17 BASE ASSEMBLY,SINGLE 3041A20021N 1 R
18 AIR GUIDE 5238A20007A 1 R
19 AIR GUIDE 5238A20009A 1 R
20 DAMPER,VENTILATION 4900A20003A 1 R
21 ORIFICE 4948A10014A 1 R
22 MOTOR ASSEMBLY,SINGLE 4681A20027X 1 R
23 SHROUD 4998A10012A 1 R
24 FAN,TURBO 5900A20020A 1 R
25 FAN ASSEMBLY,AXIAL 5900AR1167B 1 R
26 67302500 CLAMP,SPRING 3H02932B 2 R
27 BRACE 4800A30002A 1 R
28 EVAPORATOR ASSEMBLY,FIRST 5421A10026D 1 R
29 CONDENSER ASSEMBLY,BENT 5403A20043M 1 R
30 67307100 RUBBER 4H02023A 1 R
C CONTROL BOX ASSEMBLY,SINGLE 4995A20278K 1 N
31 CONTROL BOX,SINGLE 4994A10029A 1 R
32 PANEL,CONTROL 3720A10111B 1 R
33 CAPACITOR,DRAWING 6120AR2359V 1 R
34 POWER CORD ASSEMBLY 6411A20011F 1 R
35 THERMISTOR ASSEMBLY 6323A20004D 1 R
36 CONNECTOR ASSEMBLY 6631AR3843U 1 R
37 CONNECTOR ASSEMBLY 6631A30003A 1 R
38 COVER,CONTROL BOX 3550A30114A 1 R
39 PWB(PCB) ASSEMBLY,MAIN(AC) 6871A20167C 1 R
DESCRIPTION
FRIEDRICH
PART NO.
PART NO.
Q'TY
PER SET
REMARK
KP08A10
LOCATION
NO
.
