Friedrich KP08A10 - Page 35

—35—
40 PWB(PCB) ASSEMBLY,MAIN(DC) 6871A20324A 1 R
41 ESCUTCHEON 3831A10021N 1 R
42 REMOTE CONTROLLER ASSEMBLY 6711A20056U 1 R
D PIPE R
43 TUBE ASSEMBLY,SUCTION SINGLE 5211A20228F 1 R
44 TUBE ASSEMBLY,DISCHARGE SINGLE 5211A10074D 1 R
45 TUBE ASSEMBLY,FORMED COND 5211AR3399Y 1 R
46 TUBE,CAPILLARY BEND 5210A30018Q 1 R
47 TUBE ASSEMBLY,EVAPORATOR IN 5211A20470G 1 R
E INSTALL PART ASSEMBLY,SINGLE 3127AR3403M 1 R
48 UPPER GUIDE 4974AR3328C 1 R
49 67303802 CURTAIN ASSEMBLY 4959AR3402A 1 R
50 67303803 CURTAIN ASSEMBLY 4959AR3402B 1 R
51 67306500 BRACKET,ANGLE 4810AR3240A 2 R
52 67306700 NUT,HEXAGON 1NHC1000006 2 R
53 67306600 BOLT 1BHD1004006 2 R
54 67306400 FRAME GUIDE 3210AR3337A 1 R
55 67306902 WASHER,PLAN 4H01029D 1 R
56 67307000 DRAIN,PIPE 3H02773A 1 R
DESCRIPTION
FRIEDRICH
PART NO.
PART NO.
Q'TY
PER SET
REMARK
KP08A10
LOCATION
NO
.
