HOW DUCTLESS SYSTEMS WORK
Friedrich ductless split systems have the advantages of a ducted
installation without the high material and labor costs. Most systems can
be installed and running in a few hours.
Refrigerant lines and electrical pass through a 3” wall opening and run
along the exterior of the building to the condensing unit.
Electrical hard-wiring is required.
ELECTRICAL WIRING
REFRIGERANT LINES
INDOOR UNIT converts warm indoor
air to cold indoor air, conditioning and
dehumidifying the room while fi ltering the
air. Unit is mounted high on the wall.
OUTDOOR CONDENSER transfers heat to
the outdoors. Compact unit can be placed
at ground level, hung on an outside wall or
placed on the roof of a building. Maximum
line lengths from 66 ft. to 164 ft.
NOTE: Maximum lengths vary by model.
Refrigerant
and electrical
lines pass
through 3 inch
hole.
DUCTLESS
SPLIT
SYSTEMS
Amazingly quiet indoors.
Ductless split systems offer many
advantages for residential and light
commercial applications.
