SPECIFICATIONS
O
peratin
g
ran
g
e
0
°
-11
5
°
F.
Due to continuin
g
research in new ener
gy
-savin
g
technolo
gy
, speci
fi
cations are sub
j
ect to chan
g
e without notice.
Five-
y
ear warrant
y
limited to installations in the United
S
tates, Puerto Rico, Mexico and
C
anada onl
y
.
S
ee warrant
y
documentation
f
or
f
ull details.
LISTED
PDE Series
Model PDE07K PDE07R PDE09K PDE09R PDE12K PDE12R PDE15K PDE15R
PERFORMANCE DATA:
Cooling Btu 7700/7600 7700 9000/8800 9000 12000/11800 12000 15000/14600 15000
Cooling Watts 640/620 640 800/770 800 1120/1120 1120 1530/1510 1530
Energy Effi ciency Ratio EER 12.0/12.2 12.0 11.3/11.4 11.3 10.7/10.5 10.7 9.8/9.7 9.8
Moisture Removal Pts./Hr. 1.7 1.7 2.2 2.2 2.7 2.7 3.2 3.2
Sensible Heat Ratio 0.84 0.84 0.81 0.81 0.67 0.67 0.65 0.65
ELECTRICAL DATA:
Voltage (1 PHASE, 60 Hz) 230/208 265 230/208 265 230/208 265 230/208 265
Current Amps 2.8/3.0 2.4 3.7/3.9 3.7 5.1/5.3 4.8 6.7/7.5 5.9
Power Factor 0.97 0.99 0.99 0.99 0.99 0.99 0.99 0.99
Compressor LRA 19.0 12.0 17.0 18.0 27.0 23.0 32.6 27.8
Compressor RLA 2.8 2.4 3.7 2.9 5.0 4.3 6.6 5.6
Outdoor Fan Motor HP 0.024 0.024 0.029 0.029 0.031 0.031 0.031 0.031
AIRFLOW DATA:
Indoor CFM, HIGH 345/315 345 360/345 360 360/350 360 385/375 385
Indoor CFM, MED 320/290 320 330/305 330 330/310 330 360/330 360
Indoor CFM, LOW 295/265 295 300/270 300 310/280 310 320/290 320
Vent CFM 75 75 75 75 75 75 75 75
PHYSICAL DATA:
Sleeve Dimensions H x W x D In. 16"x42"x13 3/4" 16"x42"x13 3/4" 16"x42"x13 3/4" 16"x42"x13 3/4" 16"x42"x13 3/4" 16"x42"x13 3/4" 16"x42"x13 3/4" 16"x42"x13 3/4"
Dimensions with front H x W x D In. 16"x42"x21 1/2" 16"x42"x21 1/2" 16"x42"x21 1/2" 16"x42"x21 1/2" 16"x42"x21 1/2" 16"x42"x21 1/2" 16"x42"x21 1/2" 16"x42"x21 1/2"
Cut Out Dimensions H x W In. 16 1/4"x42 1/4" 16 1/4"x42 1/4" 16 1/4"x42 1/4" 16 1/4"x42 1/4" 16 1/4"x42 1/4" 16 1/4"x42 1/4" 16 1/4"x42 1/4" 16 1/4"x42 1/4"
Net Weight Lbs. 106 106 111 111 116 116 119 119
Shipping Weight Lbs. 126 126 131 131 136 136 139 139
R-410A Charge Oz. 23.63 24.69 33.51 33.51 35.27 35.98 38.10 40.21
Dimensions with Packaging In. 19.75"x23"x43.5" (all models)
PDH Series
Model PDH07K PDH07R PDH09K PDH09R PDH12K PDH12R PDH15K PDH15R
PERFORMANCE DATA:
Cooling Btu 7700/7600 7700 9000/8800 9000 12000/11800 12000 14500/14200 14500
Cooling Watts 640/620 640 800/770 800 1120/1120 1120 1480/1460 1480
Energy Effi ciency Ratio EER 12.0/12.2 12 11.3/11.4 11.3 10.7/10.5 10.7 9.8/9.7 9.8
Reverse Heating Btu 6300/6100 6300 8100/7900 8100 10700/10500 10700 13300/13000 13300
Heating Watts 540/530 540 720/770 720 1010/990 1010 1300/1270 1300
COP 3.4/3.4 3.4 3.3/3.3 3.3 3.1/3.1 3.1 3.0/3.0 3.0
Moisture Removal Pts./Hr. 1.7 1.7 2.2 2.2 2.7 2.7 3.2 3.2
Sensible Heat Ratio 0.84 0.84 0.81 0.81 0.67 0.67 0.65 0.65
ELECTRICAL DATA:
Voltage (1 PHASE, 60 Hz) 230/208 265 230/208 265 230/208 265 230/208 265
Current Amps 2.8/3.0 2.4 3.7/3.9 3.7 5.1/5.3 4.8 6.7/7.5 5.7
Reverse Heat Amps 2.4/2.5 2.1 3.4/3.8 3.4 4.5/4.7 4.5 5.8/6.2 5.0
Power Factor 0.97 0.99 0.99 0.99 0.99 0.99 0.98 0.98
Compressor LRA 19.0 12.0 18.5 19.0 27.0 23.0 36.0 26.0
Compressor RLA 2.8 2.4 3.6 3.2 5.0 4.3 6.5 5.3
Outdoor Fan Motor HP. 0.024 0.024 0.029 0.029 0.031 0.031 0.031 0.031
AIRFLOW DATA:
Indoor CFM, HIGH 345/315 345 360/345 360 360/350 360 420/390 385
Indoor CFM, MED 320/290 320 330/305 330 330/310 330 410/380 360
Indoor CFM, LOW 295/265 295 300/270 300 310/280 310 380/350 320
Vent CFM 75 75 75 75 75 75 75 75
PHYSICAL DATA:
Sleeve Dimensions H x W x D In. 16"x42"x13 3/4" 16"x42"x13 3/4" 16"x42"x13 3/4" 16"x42"x13 3/4" 16"x42"x13 3/4" 16"x42"x13 3/4" 16"x42"x13 3/4" 16"x42"x13 3/4"
Dimensions with front H x W x D In. 16"x42"x21 1/2" 16"x42"x21 1/2" 16"x42"x21 1/2" 16"x42"x21 1/2" 16"x42"x21 1/2" 16"x42"x21 1/2" 16"x42"x21 1/2" 16"x42"x21 1/2"
Cut Out Dimensions H x W In. 16 1/4"x42 1/4" 16 1/4"x42 1/4" 16 1/4"x42 1/4" 16 1/4"x42 1/4" 16 1/4"x42 1/4" 16 1/4"x42 1/4" 16 1/4"x42 1/4" 16 1/4"x42 1/4"
Net Weight Lbs. 108 108 113 113 118 118 121 121
Shipping Weight Lbs. 128 128 133 133 138 138 141 141
R-410A Charge Oz. 23.63 24.69 33.51 35.27 35.27 35.98 39.86 36.33
Dimensions with Packaging In. 19.75"x23"x43.5" (all models)
22

Friedrich MR09C1H Specifications

General

Brand	Friedrich
Model	MR09C1H
Category	Air Conditioner
Language	English
