Friedrich PTAC Series Parts Manual

A K A M 00001
LJ = 2009 AE = 2015
AK = 2010 AF = 2016
AA = 2011 AG = 2017
AB = 2012 AH = 2018
AC = 2013 AJ = 2019
AD = 2014
A = Jan D = Apr G = Jul K = Oct
B = Feb E = May H = Aug L = Nov
C = Mar F = Jun J = Sep M = Dec
PRODUCT LINE
M = PTAC
MONTH MANUFACTURED
PTAC Serial Number Identification Guide
SERIAL NUMBER
YEAR MANUFACTURED PRODUCTION RUN NUMBER
PD H 07 K 3 S E A
Engineering Digit
Design Series
Options
S = Standard
Nominal Heater Size
(@ 230V or 265V)
0 = No Heater
2 = 2.5KW
3 = 3.4KW
5 = 5.0KW
Voltage
K = 208/230V - 1Ph. - 60Hz.
R = 265V - 1Ph. - 60Hz.
Series
PD = P Series Digital PTAC
System
E = Cooling with or
without electric heat
H = Heat Pump with
Auxiliary Heat
Nominal Cooling Capacity
07 = 7000 BTUh
09 = 9000 BTUh
12 = 12000 BTUh
15 = 15000 BTUh
UNIT IDENTIFICATION
Model Number Code
2

Friedrich PTAC Series Specifications

General

Fan Speeds	2 or 3
Refrigerant	R-410A
Voltage	230/208 V
Filter Type	Washable
Noise Level	50 - 55 dB
Dimensions	Approx. 16" H x 42" W x 16" D
