Friedrich PTAC Series Parts Manual

7
PDE07K2SE-A
PDE07K3SE-A
PDE07R2SE-A
PDE07R3SE-A
PDE09K0SE-A
PDE09K2SE-A
PDE09K3SE-A
PDE09R2SE-A
PDE09R3SE-A
PDE12K0SE-A
PDE12K2SE-A
PDE12K3SE-A
PDE12K5SE-A
PDE12R2SE-A
PDE12R3SE-A
PDE12R5SE-A
PDE15K0SE-A
PDE15K3SE-A
PDE15K5SE-A
PDE15R3SE-A
PDE15R5SE-A
PDH07K2SE-A
PDH07K3SE-A
PDH07R2SE-A
PDH07R3SE-A
PDH09K2SE-A
PDH09K3SE-A
PDH09R2SE-A
PDH09R3SE-A
PDH12K2SE-A
PDH12K3SE-A
PDH12K5SE-A
PDH12R2SE-A
PDH12R3SE-A
PDH12R5SE-A
PDH15K3SE-A
PDH15K5SE-A
PDH15R3SE-A
PDH15R5SE-A
NS 25059450 EVAPORATOR COIL 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 NS 25065051 EVAPORATOR COIL 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 NS 25065551 EVAPORATOR COIL 1 1 1 1 1 1 1
1 25014860 CONDENSER COIL 1 1 1 1 1 1 1 1 1 1 1
1 25090701 CONDENSER COIL 1 1 1 25090802 CONDENSER COIL 1 1 1 1 1 1 1 1 1 1 1
1 25091200 CONDENSER COIL 1 1 1 25090803 CONDENSER COIL 1 1 1 1 1 1 1 1 1 1 1 1 1 2 25024933 COMPRESSOR KIT 265 1 1 1 1
2 25024934 COMPRESSOR KIT 265 1 1 1 1
2 25024935 COMPRESSOR KIT 230 1 1 1 1
2 25024936 COMPRESSOR KIT 230 1 1 1 1 1
2 25024937 COMPRESSOR KIT 230 1 1 1 1 1 1 1 2 25024938 COMPRESSOR KIT 265 1 1 1 1 2 25024939 COMPRESSOR KIT 265 1 1 1 2 25024940 COMPRESSOR KIT 265 1 1 1 2 25024941 COMPRESSOR KIT 230 1 1 1 1 1 3 03760513 CAP TUBE A/C, ELECTRIC ONLY 1 1 1 1 1 1 1 1
3 03760548 CAP TUBE A/C, ELECTRIC ONLY 1 1 1 3 03760543 CAP TUBE A/C, ELECTRIC ONLY 1 1 3 03760473 CAP TUBE A/C, ELECTRIC ONLY 1 1 1 1 1 1 1 1 1 1
3 03760520 CAP TUBE A/C, ELECTRIC ONLY 1 1 1 3 03760547 CAP TUBE A/C, ELECTRIC ONLY 1 1 1 1 1 1
3 03760482 CAP TUBE, COOL, HEAT PUMP 1 1 1 1 1 1 1 1 3 01390212 CAP TUBE, COOL, HEAT PUMP 1 1 1 1 1 3 01389915 CAP TUBE, HEAT, HEAT PUMP 1 1 3 03760559 CAP TUBE, HEAT, HEAT PUMP 1 1 1 1 3 03760518 CAP TUBE, HEAT, HEAT PUMP 1 1 1 4 25076001 CHECK VALVE 1 1 1 1 1 1 4 25076002 CHECK VALVE 1 1 4 25076003 CHECK VALVE 1 1 1 4 25076004 CHECK VALVE 1 1 1 1 1 1 1 5 25022022 REV. VALVE ASSEMBLY 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 6 25063605 SOLENOID COIL 230 VOLT 1 1 1 1 1 1 1 1 1 6 25063705 SOLENOID COIL 265 VOLT 1 1 1 1 1 1 1 1 1 7 60179903 BELLOWS CONDENSATE VALVE 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 8 25014502 DRAINPAN 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 9 91400400 STUD COMPR MTG 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3
10 61028900 COMPRESSOR GROMMET 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 11 25067500 AIR DEFLECTOR 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 12 25016011 DECK 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 13 25077700 HEATER 2.5KW @ 230V 1 1 1 1 1 1 13 25077701 HEATER 3.4KW @ 230V 1 1 1 1 1 1 1 1
13 25077702 HEATER 5.0KW @ 230V 1 1 1 1 13 25077703 HEATER 2.5KW @ 265V 1 1 1 1 1 1 13 25077704 HEATER 3.4KW @ 265V 1 1 1 1 1 1 1 1
13 25077705 HEATER 5.0KW @ 265V 1 1 1 1 14 25036400 SUPPORT BRACE (CONDENSER) 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 15 60542006 CONDENSER SLINGER FAN BLADE 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 16 25036801 SHROUD (CONDENSER FAN) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 17 60604109 FRESH AIR DOOR SCREEN 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 17 61031081 FRESH AIR DOOR INSULATION 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 18 25014400 MOTOR MOUNT 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 19 25014600 MOTOR, 230 VOLT 1 1 1 1 1 1 19 25014601 MOTOR, 265 VOLT 1 1 1 1 1 1 1 1
PART NO.
REF.
NO.
COOLING WITH ELECTRIC HEAT
7,000 BTU/H 9,000 BTU/H 12,000 BTU/H 15,000 BTU/H
HEAT PUMP + COOLING WITH ELECTRIC HEAT
7,000 BTU/H 9,000 BTU/H 12,000 BTU/H 15,000 BTU/H
DESCRIPTION

Friedrich PTAC Series Specifications

General

Fan Speeds	2 or 3
Refrigerant	R-410A
Voltage	230/208 V
Filter Type	Washable
Noise Level	50 - 55 dB
Dimensions	Approx. 16" H x 42" W x 16" D
