Friedrich PTAC Series Parts Manual

8
PDE07K2SE-A
PDE07K3SE-A
PDE07R2SE-A
PDE07R3SE-A
PDE09K0SE-A
PDE09K2SE-A
PDE09K3SE-A
PDE09R2SE-A
PDE09R3SE-A
PDE12K0SE-A
PDE12K2SE-A
PDE12K3SE-A
PDE12K5SE-A
PDE12R2SE-A
PDE12R3SE-A
PDE12R5SE-A
PDE15K0SE-A
PDE15K3SE-A
PDE15K5SE-A
PDE15R3SE-A
PDE15R5SE-A
PDH07K2SE-A
PDH07K3SE-A
PDH07R2SE-A
PDH07R3SE-A
PDH09K2SE-A
PDH09K3SE-A
PDH09R2SE-A
PDH09R3SE-A
PDH12K2SE-A
PDH12K3SE-A
PDH12K5SE-A
PDH12R2SE-A
PDH12R3SE-A
PDH12R5SE-A
PDH15K3SE-A
PDH15K5SE-A
PDH15R3SE-A
PDH15R5SE-A
19 25014615 MOTOR, 230 VOLT 1 1 1 1 1 1 1 1 1 1 1 1 19 25014616 MOTOR, 265 VOLT 1 1 1 1 1 1 1 1 1 1 19 25014685 MOTOR, 230 VOLT 1 1 1 20 25069000 BLOWER WHEEL 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 20 25069100 BLOWER WHEEL 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 21 25014306 SCROLL 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 22 25037301 BASEPAN, PAINTED 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 23 60500312 SUPPLY CORD 30A (5.0KW @ 230 VOLT) 1 1 1 1 23 60500385 SUPPLY CORD 15A (2.5KW @ 230 VOLT) 1 1 1 1 1 1 1 1 1
23 60500386 SUPPLY CORD 20A (3.4KW @ 230 VOLT) 1 1 1 1 1 1 1 1
24 25080050 ELECTRONIC CONTROL KIT 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 25 61925001 THERMISTOR HOLDER 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 26 25080201 HEAT/COOL ESCUTCHEON 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 27 25080301 COOL ONLY ESCUTCHEON 1 1 1 28 25080401 REMOTE THERMOSTAT ESCUTCHEON 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 29 20086915 STRAIN RELIEF 30A 1 1 1 1 1 1 1
29 25069600 STRAIN RELIEF 15-20A 1 1 1 1 1 1 1 1 1 1 1
29 25077800 STRAIN RELIEF 30A 1 1 1 30 25037905
FRONT COVER COMPLETE (W/ DOOR & FILTERS) 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
31 25031904
ASY CNTRL DOOR - FR-WHITE-2005 LOGO 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
32 25025903 GRILLE DISCHARGE - 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 33 25037804 FILTER 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
NS 21058444 FUSE HOLDER, 15A (2.5 kW) 1 1 1 1 1 1
NS 21058446 FUSE HOLDER, 20A (3.4 kW) 1 1 1 1 1 1 1 1
NS 21058447 FUSE HOLDER, 30A (5.0 kW) 1 1 1 1
NS 21058448 FUSE, TIME DELAY 15A (2.5 kW) 1 1 1 1 1 1 NS 21058449 FUSE, TIME DELAY 20A (3.4 kW) 1 1 1 1 1 1 1 1
NS 21058451 FUSE, TIME DELAY 30A (5.0 kW) 1 1 1 1
NS 25015900 FRESH AIR DOOR LATCH 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 NS 25037000 FRESH AIR DOOR 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 NS 25045100 FRESH AIR DOOR CABLE 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 NS 25060500 SPEED NUT (U-TYPE) 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 NS 25060604 THUMB SCREW 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 NS 25075801 DISCHARGE SCREEN 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 NS 60217902 SEAL MOTOR TO WALL 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 NS 61080539 CAPCTR 25/5 MF 370V (230 VOLT) 1 1 NS 61080541 CAPCTR 20/5 MF 370V (230 VOLT) 1 1 1 1 1 1 1 1 1 1 1
NS 61080543 CAPCTR 15/5 MF 370V (230 VOLT) 1 1 1 1 NS 61080549 CAPCTR 45/5 MF 370V (230 VOLT) 1 1 1 1 1
NS 61080583 CAPCTR 35/5 MF 440V (265 VOLT) 1 1 1 1 NS 61080584 CAPCTR 25/5 MF 450V (265 VOLT) 1 1 1 1 1 1 1 1 1 1 1 1 1 NS 61764541 OVERLOAD (12K-265V) 1 1 1 NS 61764569 OVERLOAD (12K-230V) 1 1 1 1 1 1 1 NS 61764571 OVERLOAD (9K-265V) 1 1 1 1 NS 61764572 OVERLOAD (7K-265V) 1 1 1 1 NS 61764574 OVERLOAD (7K-230V) 1 1 1 1
NS 61764586 OVERLOAD (15K-230V) 1 1 1 1 1
NS 61764587 OVERLOAD (12K-265V) 1 1 1 NS 61764588 OVERLOAD (9K-230V) 1 1 1 1 1 NS 61764589 OVERLOAD (15K-265V) 1 1 1 1 NS 61828204
SUCTION DRYER
(FOR HEAT PUMPS ONLY)
1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
NS 61828202 LIQUID LINE DRYER 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 NS 61883101 48 PAD ISOLATION 2X4 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 NS 61883102 48 PAD ISOLATION 3X6 2 2 2 2 2 2 2 2 2 2 2 2 2 2
PART NO.
REF.
NO.
COOLING WITH ELECTRIC HEAT
7,000 BTU/H 9,000 BTU/H 12,000 BTU/H 15,000 BTU/H
HEAT PUMP + COOLING WITH ELECTRIC HEAT
7,000 BTU/H 9,000 BTU/H 12,000 BTU/H 15,000 BTU/H
DESCRIPTION

Friedrich PTAC Series Specifications

General

Fan Speeds	2 or 3
Refrigerant	R-410A
Voltage	230/208 V
Filter Type	Washable
Noise Level	50 - 55 dB
Dimensions	Approx. 16" H x 42" W x 16" D
