18 PB
SPECIFICATIONS
Electrical Data
Electrical Wiring for 265 Volt
Models
NOTE: It is recommended that the PXSB subbase assembly, the
PXCJA conduit kit (or equivalent) be installed on all hardwire
units. If installing a ush-oor mounted unit, make sure the
chassis can be removed from the sleeve for service and
maintenance.
WARNING
Electrical Shock Hazard
Turn off electrical power before service
or installation.
ALL electrical connections and wiring
MUST be installed by a qualified
electrician and conform to the National
Code and all local codes which have
jurisdiction.
Failure to do so can result in property
damage, personal injury and/or death.
Power Cord Installation
All 265V PTAC/PTHP units come with a factory installed non-LCDI
power cord for use in a subbase. If the unit is to be hard-wired refer to
the instructions below.
To install the line voltage power leads and con-
duit to chassis, follow the instructions below
and refer to Figures 25-27 on page 19. PXCJA
Conduit Kit is required with this setup.
1. Follow the removal process of the chassis’s junction box
(Figure 25).
2. Prepare the 265V (or 230V) power cord for connection to the chas-
sis’ power cord connector by cutting the cord to the appropriate
length (refer to Figure 26 and follow Figure 15). Power cord harness
selection shown on Table 2
Table 2
Model Heater kW Power Cord Kit Voltage Amperage Receptacle
PDE/PDH07K 2.5 PXPC23015A 230/208 15 NEMA 6-15r
3.5 PXPC23020A (STD) 230/208 20 NEAM 6-20r
PDE/PDH09K 2.5 PXPC23015A 230/208 15 NEMA 6-15r
3.5 PXPC23020A (STD) 230/208 20 NEMA 6-20r
5.0 PXPC23030 230/208 30 NEMA 6-30r
PDE/PDH12K 2.5 PXPC23015A 230/208 15 NEMA 6-15r
3.5 PXPC23020A(STD) 230/208 20 NEMA 6-20r
5.0 PXPC23030 230/208 30 NEMA 6-30r
PDE/PDH15K 2.5 PXPC23015A 230/208 15 NEMA 6-15r
3.5 PXPC23020A 230/208 20 NEMA 6-20r
5.0 PXPC23030 (STD) 230/208 30 NEMA 6-30r
PDE/PDH07R 2.5 PXPC26515A 265 15 NEMA 7-15r
3.5 PXPC23020A (STD) 265 20 NEMA 7-20r
PDE/PDH09R 2.5 PXPC26515 265 15 NEMA 7-15r
3.5 PXPC23020A (STD) 265 20 NEMA 7-20r
5.0 PXPC26530 265 30 NEMA 7-30r
PDE/PDH12R 2.5 PXPC26515A 265 15 NEMA 7-15r
3.5 PXPC23020A (STD) 265 20 NEMA 7-20r
5.0 PXPC26530 265 30 NEMA 7-30r
PDE/PDH15R 2.5 PXPC26515A 265 15 NEMA 7-15r
3.5 PXPC26520A 265 20 NEMA 7-0r
5.0 PXPC23030 (STD) 265 30 NEMA 7-30r
Table 2
Model Heater kW Power Cord Kit Voltage Amperage Receptacle
PZE/PZH07K 3.6 PXPC23020A (STD) 230/208 20 NEMA 6-20r
PZE/PDZ09K 3.6 PXPC23020A (STD) 230/208 20 NEMA 6-20r
PZE/PZH12K 3.6 PXPC23020A(STD) 230/208 20 NEMA 6-20r
PZE/PZH15K 5.0 PXPC23030 (STD) 230/208 30 NEMA 6-30r
PDE/PDH09R 3.6 PXPC23020A (STD) 265 20 NEMA 7-20r
PDE/PDH12R 3.6 PXPC26530 265 30 NEMA 7-30r
