ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 67808000 FRONT GRILL ALL 1
2 67808001 PANEL COVER ALL 1
3 67808002 ELECTRICAL DOOR ALL 1
4 67808003 INDOOR MOTOR MOUNT ALL 1
5.1 67808004 INDOOR MOTOR CAPACITOR 450V
1.5UF
PZH07K3SB, PZH09K3SB, PZH12K3SB, PZH15K3SB 1
5.2 67808005 OUTDOOR MOTOR CAPACITOR
450V 3UF
PZH07K3SB, , PZH09K3SB, PZH12K3SB, PZH15K3SB 1
5.2 67808078 OUTDOOR MOTOR CAPACITOR PZH09R3SB 1
5.2 67808089 OUTDOOR MOTOR CAPACITOR PZH12R3SB 1
5.3 67808006 ELECTRIC HEATER RELAYS ALL 1
6 67808007 MAIN PCB ALL 1
7 67808008 ELECTRICAL BOX BOTTOM
COVER
ALL 1
8 67808009 TERMINAL BLOCK ALL 1
9 67808010 ELECTRICAL BOX SIDE COVER ALL 1
10 67808011 POWER CORD PLATE ALL 1
11 67808012 PCB STAND OFF ALL 1
12 67808013 AIR GUIDE PLATE 2 ALL 1
13 67808014 DISPLAY OVERLAY ALL 1
14 67808015 SEAL BRACKET ALL 1
15 67808016 24V TRANSFORMER PZH07K3SB, PZH09K3SB, PZH12K3SB, PZH15K3SB 1
15 67812179 24V TRANSFORMER PZH09R3SB, PZH12R3SB 1
16 67812092 POWER CORD FASTENER PZH07K3SB, PZH12K3SB, PZH12R3SB 1
16 67808063 POWER CORD FASTENER PZH09K3SB 1
16 67808017 POWER CORD FASTENER PZH15K3SB 1
17 67808065 COMPRESSOR PZH07K3SB 1
17 67808074 COMPRESSOR PZH09K3SB 1
17 67808080 COMPRESSOR PZH09R3SB 1
17 67808090 COMPRESSOR PZH12R3SB 1
17 67808018 COMPRESSOR PZH15K3SB
18 67808019 CAPACITOR BRACKET ALL 1
19 67808072 COMPRESSOR CAPACITOR PZH07K3SB 1
19 67808075 COMPRESSOR CAPACITOR 450V
20UF
PZH09K3SB 1
19 67808081 COMPRESSOR CAPACITOR PZH09R3SB 1
19 67808020 COMPRESSOR CAPACITOR PZH12R3SB, PZH15K3SB 1
19 67808091 COMPRESSOR CAPACITOR PZH12R3SB 1
20 67808021 CABLE CAP ALL 1
21 67808071 OUTDOOR MOTOR PZH07K3SB, PZH09K3SB, PZH12K3SB 1
Figure 902
PARTS CATALOG
PZH07K3SB, PZH09K3SB, PZH09R3SB, PZH12K3SB, PZH12R3SB, PZH15K3SB
