92 PB
PARTS CATALOG
PZH07K3SB, PZH09K3SB, PZH09R3SB, PZH12K3SB, PZH12R3SB, PZH15K3SB
Figure 902
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
46 67808047 CHECK VALVE PZH15K3SB 1
47 67808048 LEFT PANEL ALL 1
48.1 67808049 FRESH AIR FILTER GUIDE ALL 1
48.2 67808050 FRESH AIR FILTER LEVER ALL 1
49 67812176 SUPPORT BRACKETS PZH12K3SB, PZH15K3SB 1
49 67812169 SUPPORT BRACKETS PZH07K3SB, PZH09K3SB, PZH09R3SB, PZH12R3SB 1
50.1 67808051 FRESH AIR WIRE ALL 1
50.2 67808053 FRESH AIR DOOR BUSHING ALL 1
51 67808054 OUTDOOR MOTOR BRACKET ALL 1
52 67808055 FAN SHROUD TOP ALL 1
53 67808056 RIGHT CORNER POST ALL 1
54 67808057 LEFT CORNER POST ALL 1
55 67808058 BEARING SEAL PLATE ALL 1
56 67808059 INDOOR FOAM PAN ALL 1
57 67808060 FRESH AR DOOR CABLE HOLDER ALL 1
58 67808061 FRESH AIR DOOR ALL 1
59 67808073 ELECTRIC HEAT ELEMENT PZH07K3SB 1
59 67808073 ELECTRIC HEAT ELEMENT PZHO9K3SB, PZH12K3SB 1
59 67808086 ELECTRIC HEAT ELEMENT PZH09R3SB, PZH12R3SB 1
59 67808062 ELECTRIC HEAT ELEMENT PZH15K3SB 1
-61 67812089 SADDLE CLIP ALL 1
-62 67812171 COMPRESSOR HARNESS ALL 1
-63 67812091 DISPLAY PCB ALL 1
-64 67808063 POWER CORD FASTENER PZH07K3SB, PZHO9K3SB, PZH09R3SB, PZH12K3SB 1
-64 67812114 POWER CORD FASTENER PZH15K3SB 1
-65 67812093 DISPLAY ESCUTCHEON ALL 1
-66 67812094 ROOM TEMP SENSOR ALL 1
-67 67812095 INDOOR COIL SENSOR ALL 1
-68 67812096 OUTDOOR COIL SENSOR ALL 1
69 67812097 DISCHARGE AIR SENSOR ALL 1
-70 67812098 POWER CORD LCDI ALL 1
-71 67808064 SEAL PLATE ALL 1
-72 67812172 PANEL CLIP ALL 1
-73 67812100 BELLOWS VALVE ALL 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
