Friedrich SQ06 - Items Required for Installation (Provided in Straight Cooling Units Only)

22
FRR084
ITEM #2
ITEM #3
ITEM #4
ITEM #5
ITEM #6
ITEM #1
ITEM #9
ITEM #8
ITEM #10
ITEM #7
ITEMS NOT TO SCALE
Items required for installation (provided in straight cooling units only)
ITEM NO DESCRIPTION QTY.
1
2
3
4
SCREW, SHEET METAL, #8 x "
SCREW, PHILLIPS, TRUSS HEAD, #8 x ½"
SCREW, HEX, #8 x
"
SCREW, PHILLIPS, #8 x 1 ¼"
8
4
10
2
5
6
GRAY GASKET, FOAM, 1" x 1 ½" x 42"
WHITE GASKET, FOAM, 1" x 1 ½" x 48"
1
1
ITEM NO DESCRIPTION QTY.
7
8
LEFT SIDE CURTAIN ASSEMBLY
RIGHT SIDE CURTAIN ASSEMBLY
1
1
9
10
CABINET OR SLEEVE w/ TOP ANGLE BAR
(TOP ANGLE BAR NOT INCLUDED ON EQ)
AIR CONDITIONING UNIT w/ DECORATIVE
FRONT PANEL
1
1
1
Recommended tools required for installation: (not included)
HEXHEAD SCREWDRIVER
COMMON SCREWDRIVER
PHILLIPS SCREWDRIVER
