CAUTION
Excessive Weight Hazard
Use two or more people when
installing your air conditioner.
Failure to do so can result in
back or other injury.
CAUTION
Cut/Sever
Although great care has been
taken to minimize sharp edges
in the construction of your unit,
use gloves or other hand
protection when handling unit
Failure to do so can result in minor
to moderate personal injury.
FRR088
CHASSIS SEAL
GASKET
GRAY FOAM
GASKET
(SEE ILLUSTRATION
ITEM #5 ON PAGE 22)
TO PREVENT AIR LEAKS AROUND THE AIR
CONDITIONER, INSERT THE WHITE FOAM
GASKET (ITEM #6, PAGE 22) BETWEEN THE
AIR CONDITIONER AND THE CABINET
FRR089
NOTCHES PROVIDED FOR
ELECTRICAL CORD EXIT
Front cover removal required
for electrical cord exit.
See Figures 18A and
18B for instruction.
SCREW, #8 x 1/2” PHILLIPS
HEAD (SEE ILLUSTRATION
ITEM #2, PAGE 22)
2 REQUIRED (1 EACH SIDE)
Figure 16
Figure 17
