Friedrich VERT-I-PAK Series Engineer's Manual

14
Vert-I-Pak
®
Single Package Heat Pumps
MODEL IDENTIFICATION GUIDE
Electric Heater Size
A Series
25 = 2.5 KW
34 = 3.4 KW
50 = 5.0 KW
75 = 7.5 KW*
10 = 10 KW*
MODEL NUMBER V H A 09 K 34 RT N
Marketing Model
Options
RT = Standard Remote Operation
* 24000 Btu only.
Voltage
K = 208/230V-1Ph-60Hz
R = 265V-2Ph-60Hz
Nominal Capacity
A Series (Btu)
09 = 9,000 18 = 18,000
12 = 12,000 24 = 24,000
Series
VHA=Vertical Heat Pump
Refer to electrical data chart for heater/unit compatibility.
PURCHASER P.O. # DATE
PROJECT LOCATION
ENGINEER ARCHITECT
SUBMITTED BY FOR APPROVAL FOR REFERENCE
ITEM PLAN DESIGNATION QUANTITY COOLING Btu VOLTAGE FRIEDRICH MODEL
A-SERIES ACCESSORIES (Wall Plenum and Outdoor Louver are required)
VPAWP1-8 Adjustable Wall Plenum (5 ½"- 8") Qty
VPAWP1-14 Adjustable Wall Plenum (8"-14") Qty
VPAL2 Architectural Louver Qty
VPSC2 Architectural Louver (color matched) Qty
VPASA1 Sleeve adapter for exact t in existing
First Company SPXR-series
Qty
VPRG4 Return Air Grille/Access Panel Qty
VPDP1 Drain Pan for all A Series 18,000 and
24,000 Btu
Qty
RT6 Wired Digital Wall Thermostat Qty
RT6P Wired Programmable Wall Thermostat Qty
WRT1 Wireless Digital Wall Thermostat Qty
EMRT1 Wired Thermostat with Occupancy Sensor Qty
EMWRT1 Wireless Thermostat with Occupancy
Sensor
Qty
EMOCT Online Connection Kit Qty
EMRAF Remote Access Fee Qty
EMRHCF Energy Management Remote
Humidity Control Fee
Qty
VERT-I-PAK
®
SUBMITTAL_2017
