To Next PageTo Next PageWhat to do if the high pressure switch is open on my Friedrich Heat Pump?
If the high pressure switch is open in your Friedrich Heat Pump, it could be due to a faulty pressure switch or the discharge pressure being too high. Check the connection points and confirm system pressures and operation. If operating in cooling mode, ensure the outdoor condensing fan motor is running.
What causes a high pressure switch lockout in a Friedrich Heat Pump?
If the high pressure switch lockout occurs on your Friedrich Heat Pump, it could be caused by a faulty pressure switch or excessively high discharge pressure. Begin by checking the connection points. Next, verify the system pressures and overall operation, taking corrective measures as necessary. If the unit is in cooling mode, ensure that the outdoor condensing fan motor is functioning correctly.
Why is the low pressure switch open on my Friedrich Heat Pump?
If the low pressure switch is open on your Friedrich Heat Pump, it could be due to a faulty pressure switch or the suction line pressure being too low. Check the connection points and confirm system pressures and operation, addressing any issues found. Also, if in cooling mode, ensure the indoor blower is running.
What does it mean when the low pressure switch lockout occurs on a Friedrich VERT-I-PAK VHA09K25RTQ Heat Pump?
If a low pressure switch lockout occurs with your Friedrich Heat Pump, the possible cause is a faulty pressure switch or suction line pressure that is too low. Start by confirming the connection points. Then, check the system pressures and operation, and address any issues. If the unit is cooling, verify that the indoor blower is running.
How to fix a coil sensor failure on a Friedrich VERT-I-PAK VHA09K25RTQ Heat Pump?
If your Friedrich Heat Pump displays a coil sensor failure, it means an open or shorted sensor has been detected. First, check the connection points. Then, use an ohmmeter to test the sensor to see if it's open (OL) or shorted (0.0 Ohms). If the sensor tests ok, replace the board. Refer to Appendix 1 (Thermistor resistor values).
What causes an ambient sensor failure in a Friedrich VERT-I-PAK VHA09K25RTQ?
If your Friedrich Heat Pump is showing an ambient sensor failure, this indicates that an open or shorted sensor has been detected. Begin by checking all connection points. Next, use an ohmmeter to check the sensor for an open (OL) or shorted (0.0 Ohms) circuit. If the sensor appears to be functioning correctly, the next step is to replace the board. For reference, see Appendix 1 (Thermistor resistor values).
How to troubleshoot a Friedrich VERT-I-PAK VHA09K25RTQ Heat Pump with a control fault (no power)?
If your Friedrich Heat Pump is experiencing a control fault and has no power, confirm the incoming voltage. If voltage is present, replace the board.
General| Cooling Capacity (BTU/hr) | 9, 000 |
|---|---|
| Heating Capacity (BTU/hr) | 9, 000 |
| Voltage | 208/230V |
| Refrigerant | R-410A |
| Phase | 1 |
| Model Number | VHA09K25RTQ |
| Brand | Friedrich |
| Product Line | VERT-I-PAK |
| Unit Type | Heat Pump |
| Operating Range (Heating) | 20°F - 75°F |
