CHASSIS SPECIFICATIONS K-Series models 230/208V, R-Series models 265V
     
MODEL VHA09K VHA09R VHA12K VHA12R VHA18K VHA18R VHA24K VHA24R
COOLING DATA
COOLING BTU
9400/9400 9400 12200/12000 12400 18200/18000 18000 23000/22800 22500
POWER (W) 905/905 915 1220/1200 1240 1825/1800 1815 2527/2505 2475
EER 10.4/10.4 10.3 10.0/10.0 10.0 10.0/10.0 10.0 9.1/9.1 9.1
SENSIBLE HEAT RATIO 0.76 0.77 0.75 0.75 0.66 0.70 0.70 0.70
HEATER SIZE (kW) 2.5/3.4/5.0 2.5/3.4/5.0 2.5/3.4/5.0 2.5/3.4/5.0 2.5/3.4/5.0 2.5/3.4/5.0 2.5/3.4/5.0/7.5/10.0 2.5/3.4/5.07/7.5/10.0
HEAT PUMP DATA
REVERSE HEATING BTU
8400/8400 8500 11100/10900 11300 16800/16400 16700 20000/20000 20000
COP @ 47F 3.0/3.0 3.0 3.0/3.0 3.0 3.0/3.0 3.0 3.0/3.0 3.0
HEATING POWER (W) 830/830 820 1075/1050 1095 1650/1600 1620 1953/1953 1950
HEATING CURRENT (A) 4.0/4.0 3.2 5.0/5.3 4.5 7.8/8.3 6.9 8.5/9.4 8.1
ELECTRICAL DATA
VOLTAGE (1 PHASE, 60 HZ)
230/208 265 230/208 265 230/208 265 230/208 265
VOLT RANGE 253-197 292/239 253-197 292/239 253-197 292-239 253-197 292-239
COOLING CURRENT (A) 4.3/4.3 3.5 5.7/5.9 5.1 8.6/9.2 7.6 10.9/10.6 9.7
AMPS L.R 21.0 21.0 30.0 30.0 42.0 42.0 46.0 46.0
AMPS F.L. 3.5 3.5 4.8 4.8 7.8 7.8 9.5 9.5
INDOOR MOTOR (HP) 1/4 1/4 1/4 1/4 1/4 1/4 1/4 1/4
INDOOR MOTOR (A) 1.2 1.2 1.2 1.2 1.2 0.42 1.9 1.8
OUTDOOR MOTOR (HP) — — — — 1/4 1/4 1/4 1/4
OUTDOOR MOTOR (A) — — — — — 0.9 0.85 0.85
PHYSICAL
DIMENSIONS (W X D X H)
23”x23”x32” 23x23x32 23”x23”x32” 23x23x32 23”x23”x47” 23”x23”x47” 23”x23”x47” 23”x23”x47”
NET WEIGHT (LBS) 142 144 147 149 190 192 205 207
SHIPPING WEIGHT (LBS) 164 166 169 171 216 218 231 233
TEST SETTING LOW LOW LOW LOW HIGH HIGH LOW LOW
R410A CHARGE (OZ) 38 39 39.5 37 54 52.8 65 65
AIRFLOW DATA
INDOOR CFM
LOW HIGH LOW HIGH LOW HIGH LOW HIGH LOW HIGH LOW HIGH LOW HIGH LOW HIGH
.10” ESP 420 450 420 450 420 450 390 450 420 465 420 465 610 700 610 700
.15” ESP 405 425 405 425 405 425 375 425 390 420 390 420 585 670 585 670
.20” ESP 385 400 385 400 385 400 350 400 345 380 345 380 560 640 560 640
.25” ESP 355 375 355 375 355 375 325 375 300 325 300 325 535 610 535 610
.30” ESP 320 350 320 350 320 350 320 350 255 280 255 280 510 580 510 580
VENT CFM 60 60 60 60 60 60 60 60
 ASHRAE 90.1-2013 Compliant Model
NOTES:
Cooling Standards: 95°F DB/75°F WB OUTDOOR, 80°F DB/67°F WB INDOOR
Heating Standards: 47°F DB/43°F WB OUTDOOR, 70°F DB/60°F WB INDOOR
Normal Value Wet Coil @ .1” ESP.
Rated CFM at Low Speed: VHA09….420 VHA12….420
VHA18….420 VHA24….610
Due to continuing research in new energy-saving technology, specications are subject to change without notice.
