85 PB
FIGURE 903
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
5 62101210 HEATER 3.4 KW TTW @ 230V WHT12A33A, WET10A33A, WET12A33A, WET16A33A 1
10 61999802 FLANGE AIR DEFLECTOR ALL 1
15 61821800 SHIELD HEAT SMALL WHT12A33A, WET10A33A, WET12A33A, WET16A33A 1
20 62101400 INSUL R/SIDE TTW ALL 1
25 62100601 BLOWER FRONT 2" CAP TTW WHT12A33A, WET10A33A, WET12A33A, WCT08A10A,
WCT10A10A, WCT10A30A, WCT12A30A, WCT12A30B
1
25 62100600 BLOWER FRONT 2 1/2" CAP TTW WET16A33A, WCT12A10A, WCT12A10B, WCT16A30A 1
30 61080523 CAPTCR 25/12.5/450VAC 2.0 WHT12A33A, WET12A33A, WCT12A30A, WCT12A30B 1
30 61080584 CAPCTR 25/5 MF 450V 2.0 WET10A33A, WCT10A30A, 1
30 61080591 CAPCTR 40/7.5 MF 450V 2.5 WET16A33A, WCT16A30A 1
30 61080569 CAPCTR 60/10 MF 370V 2.5 WCT12A10A 1
30 61080605 CAPCTR 70/10 MF 370V 2.5 WCT12A10B 1
30 61080582 CAPCTR 55/10 MF 370V 2.0 WCT08A10A, WCT1010A 1
35 60610626 WHEEL BLWR 7.00X6.43X3X59 ALL 1
40 62102100 SCROLL TTW ALL 1
45 60500388 SUPPLY CORD 20A 250V 12AWG
STR ELE
WHT12A33A,, WET10A33A, WET12A33A, WET16A33A 1
45 60500384 SUPPLY CORD 13A 250V 16AWG
STR ELE
WCT10A30A, WCT12A30A, WCT12A30B, WCT16A30A 1
45 60500382 SUPPLY CORD 15A 125V 14AWG
STR ELE
WCT08A10A, WCT10A10A, WCT12A10A, WCT12A10B 1
50 62100150 L/S PANEL 05 WLMSTR ALL 1
55 62108800 INNERWALL SPOTWELD ASSY ALL 1
60 60217902 SEAL FAN MTR TO INNER WALL ALL 1
65 61871532 MTR 1/5 1 6P CCW 2 ECM WHT12A33A 1
65 61871503 MTR 1/10 4 6P CCW 2 PSC 5 WM WET10A33A 1
65 61871479 MTR 1/6 4 4P CCW 2 PSC 12.5 WM WET12A33A, WCT12A30A, WCT12A30B 1
65 61871537 MTR 1/4 4 4P CCW 2 PSC 7.5 WM WET16A33A, WCT16A30A 1
65 61871477 MTR 1/10 1 6P CCW 2 PSC 10 WM WCT08A10A, WCT10A10A 1
65 61871503 MTR 1/10 4 6P CCW 2 PSC 5 WM WCT10A30A 1
65 61871476 MTR 1/5 1 4P CCW 2 PSC 10 WM WCT12A10A, WCT12A10B 1
70 60640600 CUP RETAINER ALL 3
75 60640500 GROMMET BISCUIT #64045 ALL 3
80 01336910 SLEEVE 7/16 11- 32X9/16 PR 258 ALL 3
85 91100700 WASHER CONICAL ALL 3
90 91003000 NUT HEX .312-18 SELF LOCKING ALL 3
95 62102000 SHROUD TTW ALL 1
100 62101505 FAN 13” CW 6BL .500 ALL 1
-105 62100700 COVER TOP TTW WHT12A33A, WET16A33A 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
PARTS CATALOG
