5
Key Part Number Description 07 09 12 15 Notes
10 25016900 Coil, Evaporator 1
25018600 Coil, Evaporator 1 1 1
N/S 20094777 Capillary, Tube .054X37" 1
21058777 Capillary, Tube .054X22" 1
21058804 Capillary, Tube .064X24" 1
21058885 Capillary, Tube Heating/Cooling .070X29" 1 *
NS 21058713 Capillary, Tube Heating .049X17" 1 Heat Pump
21058787 Capillary, Tube Heating .049X13" 1 Heat Pump
21058812 Capillary, Tube Heating .049X17" 1 Heat Pump
NS 21058587 Check Valve 1 1 Heat Pump
21058568 Check Valve 1
NS 25018200 Reversing Valve (less coil) 1 1 Heat Pump
25018300 Reversing Valve (less coil) 1 1 Heat Pump
NS 21058643 Solenoid Coil Reversing Valve (230V) 1 1 1 1 Heat Pump
21058644 Solenoid Coil Reversing Valve (265V) 1 1 1 1 Heat Pump
11 25024901 Compressor 230V 1
21058641 Compressor 230V 1
21091571 Compressor 230V 1
21091573 Compressor 230V 1
25024900 Compressor 265V 1
21058642 Compressor 265V 1
21091572 Compressor 265V 1
21091574 Compressor 265V 1
12 25017000 Coil, Condenser 1 1
25017100 Coil, Condenser (Seacoast Protection)11
25019100 Coil, Condenser 1 1
25019200 Coil, Condenser (Seacoast Protection)11
13 21058599 Overload, Compressor 230V 1
21090197 Overload, Compressor 230V 1
60364596 Overload, Compressor 230V 1
61764506 Overload, Compressor 230V 1
21058614 Overload, Compressor 265V 1
21058621 Overload, Compressor 265V 1
21090034 Overload, Compressor 265V 1
21091325 Overload, Compressor 265V 1
14 25025900 Interior Grill (Starting w/ Serial No, JGJP) 1 1 1 1
15 21058694 Screen 1 1 1 1
16 25026100 Cut Off Plate - Evaporator 1 1 1 1
17 21058833 Outdoor Condenser Cutoff 1 1 1 1
18 21058553 Condensate Tube 1 1 1 1
19 21058876 Distribution Tray 1 1 1 1
20 21058402 Filter 1 1 1 1 note 1
25025600 Filter (top removal only) 1 1 1 1 note 2
21095059 Filter (Heavy Duty; 10 Pack Only) note 1
Unit Assembly Parts List
* A single capillary tube is used for both heating and cooling
** Units JGHP and prior require both the intake grille and the cutoff plate if either is to be replaced.
