Page 5
Key Part Number Description 07 09 12 15 Notes
31 21058386 Blower Housing 1 1 1
21058867 Blower Housing 1
32 21062325 Blower Access Cover 1 1 1 1
33 21062145 Plate, Bearing Support 1 1 1 1
34 21058350 Scroll, Blower with Insulation 1 1 1
21059150 Scroll, Blower with Insulation 1
35 25007800 Blower Wheel, Indoor (evaporator) 1 1 1 1
36 25007801 Blower Wheel, Outdoor (condenser) 1 1 1
25007802 Blower Wheel, Outdoor (condenser) 1
37 21064013 Belt (black) 1 1 1
21064014 Belt (clear) 1
38 25009500 LH Pulley & Bearing Assy (outdoor wheel) 2.0” 1 1
25009400 LH Pulley & Bearing Assy (outdoor wheel) 2.5” 1 1
39 25009200 RH Pulley & Bearing Assy (Indoor wheel) 3.0” 1 1 1
25009300 RH Pulley & Bearing Assy (Indoor wheel) 2.5” 1
40 25009600 Short Shaft Bearing Assy (indoor wheel) 1 1 1 1
41 21062146 Isolator (without hole, pulley end) 2 2 2 2
42 21063375 Isolator (with hole idle end) 1 1 1 1
43 21058509 Bearing Cap 1 1 1 1
44 25021000 Outdoor Blower Flex Hub 1 1 1 1
NS 25009700 RH Collar Plate 1 1 1 1
NS 25009800 LH Collar Plate 1 1 1 1
45 21061128 Motor, 230V 1/10hp 1
21061127 Motor, 230V 1/4hp 1 1
21061131 Motor, 230V 1/4hp 1
21061130 Motor, 265V 1/8hp 1 265V
21061129 Motor, 265V 1/5hp 1 1 265V
21061132 Motor, 265V 1/4hp 1 265V
46 21058397 Vent Door 1 1 1 1
NS 21058398 Vent Door Lever 1 1 1 1
NS 21058530 Spring, Vent Door Lever 1 1 1 1
47 25006500 Retainer, Insulation 1 1 1
25006501 Retainer, Insulation 1
48 21058387 Insulation, Blower Access Cover 1 1 1 1
49 21058512 Heater, 2.5kW @ 230V 1 1 1 1
21058513 Heater, 3.4kW @ 230V 1 1 1 1
21058522 Heater, 5.0kW @ 230V 1 1 1 1
21058523 Heater, 2.5kW @ 265V 1 1 1 1 265V
21058524 Heater, 3.4kW @ 265V 1 1 1 1 265V
21058525 Heater, 5.0kW @ 265V 1 1 1 1 265V
50 21058407 Limit Switch, 2.5kW Heater 1 1 1 1
21058408 Limit Switch, 3.4kW Heater 1 1 1 1
21058409 Limit Switch, 5.0kW Heater 1 1 1 1
51 21059141 Baffle 1 1 1 1
Air Handler Parts List
