Friedrich WallMaster WS12C10 User Manual

6
2010 PERFORMANCE DATA
*
Sleeve / Chassis Dimensions
27" Sleeve
Height (inches) 16 3/4 16 3/4 16 3/4
Width (inches) 27 27 27
Depth (inches) 16 3/4 16 3/4
Friedrich WSC
Sleeve
Fedders A
Sleeve
Fedders B Sleeve*
Sleeve Dimensions
Width Max. Depth
WSD Sleeve 16 3/4 27 16 3/4 23 7 1/2 9/16 17 1/4 27 1/4 15 5/16
Chassis 15 3/4 26 1/2 21 22 - - - - -
Depth
with
Front
Minimum
Extension
Into Room
Minimum
Extension
Outside
Height
TTW Finished Hole
Height Width Depth
Model
WALLMASTER
Specifications
WallMaster Heat Pump heating information (shown in red) indicates heat pump heating performance. WallMaster Electric Heat heating information (shown in red)
indicates electric heat strip performance. For WallMaster Heat Pump electric heating performance refer to corresponding WallMaster Electric Heat model.
Estar
Model
Cooling
Capacity Btu
Heating
Capacity Btu
Volts
Rated
Cooling
Amps Cooling Watts
Heating
Amps
Heating
Watts
Energy
Efficiecy Ratio
EER
Moisture
Removal
Pints/HR
Room
Side Air
Circulation
CFM Sleeve
Net Weight
Lbs
WALLMASTER
Cool only
WS08C10
*
7800 NA 115 7.1 788 NA NA 9.9 1.2 250 WSD 93
WS10C10
*
9700 NA 115 10.0 1032 NA NA 9.4 2.4 257 WSD 103
WS12C10
*
11900 NA 115 11.8 1266 NA NA 9.4 3.3 295 WSD 112
WS10C30
*
9500/9200 NA 230/208 4.5/4.7 989/958 NA NA 9.6/9.6 1.5 300 WSD 101
WS13C30
*
12600/12300 NA 230/208 6.3/6.7 1340/1309 NA NA 9.4/9.4 3.6 290 WSD 109
WS15C30
*
14500/14500 NA 230/208 8.3/8.2 1706/1706 NA NA 8.5/8.5 4.2 290 WSD 119
Heat Pumps
WY09C33
*
9300/9000 7300/7300 230/208 4.4/4.7 989/957 3.8/4.0 839/793 9.4/9.4 2.1 250 WSD 103
WY12C33
*
12000/11800
9350/9200 230/208 6.1/6.4 1395/1372 4.8/5.1 1062/1010 8.6/8.6 2.6 275 WSD 111
Cool with Electric Heat
WE10C33
*
9500/9200 11000/9100 230/208 4.5/4.7 989/958 16.0/14.7 3550/2950 9.6/9.6 1.5 300 WSD 121
WE13C33
*
12600/12300
11000/9100 230/208 6.3/6.7 1340/1309 16.0/14.7 3550/2950 9.4/9.4 3.6 290 WSD 107
WE15C33
*
14500/14500
11000/9100 230/208 8.3/8.8 1706/1706 16.0/14.7 3550/2950 8.5/8.5 4.2 290 WSD 116
DEFROST CONTROL: Initiated at 30°F (outdoor coil temperature for two
consecutive minutes) and terminated at 43°F (outdoor coil temperature). During
defrost, the compressor stops and the electric heat starts, then operates with
the fan to maintain indoor comfort. The unit remains in electric heat mode.
DEFROST DRAIN: Drain automatically opens at approximately 50°F to prevent
condensate from freezing
inside drain pan.
Note: all models will produce condensate. If condensate disposal is desired, an
optional drain kit is available.
As an partner, Friedrich Air Conditioning Co. has determined that the selected
(
) meet the guidelines for energy efficiency.
All models use
environmentally
friendly R-410A
refrigerant.
R-410A
WS08C10
*
57 23 55 60 129 167 65 98 11 31 154 462 7.1 32.0 32.5 257 1085 15
WS10C10
*
53 27 53 53 134 177 63 98 10 36 145 500 10.0 40.0 37.0 260 1080 15
WS12C10
*
54 26 52 55 128 169 60 106 11 28 145 500 11.8 57.0 45.0 300 1380 15
WS10C30
*
55 25 55 60 123 165 66 100 14 28 155 440 4.5 18.5 39.0 300 1400 15
WS13C30
*
51 29 51 51 134 179 59 100 8 40 138 535 6.3 26.0 40.0 280 1300 15
WS15C30
*
45 35 45 46 135 181 54 101 9 40 130 545 8.3 41.0 49.0 250 1345 15
WY09C33
*
54 26 54 54 123 164 65 101 12 22 150 450 4.4 3.8 20.0 40.5 251 1335 20
WY12C33
*
51 29 51 51 127 147 58 101 12 26 145 475 6.1 4.8 33.0 265 1330 20
WE10C33
*
56 24 56 56 128 150 58 110 4 24 153 477 4.5 16.0 18.5 39.0 260 1455 20
WE13C33
*
46 34 46 46 128 174 55 99 9 34 135 500 6.3 16.0 26.0 40.0 240 1350 20
WE15C33
*
45 35 45 46 135 181 54 101 9 40 130 545 8.3 16.0 41.0 43.0 250 1345 20
*
Due to continuing research and technology, performance data and 8th character (engineering) are subject to change without notice.
** Rating Conditions: 80 degrees F, room air temp. & 50% relative humidity, with 95 degree F, outside air temp & 40% relative humidity, all systems use R410A
Dischar
ge
Temp
Suction
Temp
Liquid
Temp
Super
Heat
Evap
CFM
Motor
RPM
Locked
Rotor Amps
Charge in
OZ.
BREAKER
FUSE
60 Hertz
Amps
Sub-
Coolin
g
OPERATING
PRESSURES
ELECTRICAL RATINGS R410A
Suction
Dischar
ge
Amps
Cool
Amps
Heat
WALLMASTER
EVAPORATOR AIR TEMP.
DEG. F
EVAPORATOR TEMP.
DEG. F
CONDENSER
TEMPERATU
RE DEG. F
Discharge Air
Temp. Drop
F.
T(in) T(out)
COOLING
PERFORMANCE
DATA**
19 3/4
* Due to continuing research in new energy-saving technology, specifi cations are subject to change without notice.
*
Due to continuing research in new energy-saving technology, performance data and 8th and 9th character are subject to change without notice.
