BEFORE SETTING SURFACE CONTROLS
Install Burner Grates
To install burner grates, place the grates fl at-side
down and align them into the cooktop recess.. The
grates have tabs that interlock, so it is important to
place the center grate fi rst.
IMPORTANT
• Make sure the burner grates are proper-
ly placed on the cooktop before using the
surface burners (Figure 4). The grates are
designed to rest inside the recess on the
cooktop.
• Grates should rest fl ush against each other
and against the sides of the recess.
• Do not line the area underneath the grates or
any part of the cooktop with aluminum foil or
with any other lining.
Figure 5: Install grates middle-fi rst
