Drill Pilot Holes and Fasten Bracket - Drilla 1/8"pilot
holewhere screwsare to be located. If bracket isto be
mountedtothe wall,drillpilothole atan approximate20°
downwardangle. If bracketisto be mountedto masonry
orceramicfloors,drilla 5/32" pilothole 1-3/4"deep. The
screws provided may be used in wood or concrete
material. Use a 5/16" nut-driverorflat head screwdriver
to securethe bracketin place.
FASTEN BRACKET (W*_LOr FLOOrMOUNTING)
--_l 1<--1-1/4"Max.
Leveling Leg I
Mount
Floor Mount _ I--Anti-Tip Bracket
FASTEN BRACKET (FLOOR MOUNTING ONL'd
Leveling Leg --
N
FloorlM°unt _i LAntI'Tip Bracket
- More Than
1-1/4"
Wall
C. Level and Position Range - Level range by adjusting
the (4) levelinglegs with a wrench. Note: A minimum
clearanceof 1/8" is required between the bottomof the
rangeand theleveling legto allow roomfor the bracket.
Usea spiritlevelto checkyouradjustments. Slide range
back into position. Visually check thatrear levelingleg is
inserted into and fully secured by the Anti-Tip Bracket by
removing lower panel or storage drawer. For modelswith
a warmer drawer or broiler compartment, grasp the top
rear edge of the range and carefully attempt to tilt it
forward.
2. Electrical Connection Requirements
Thisappliancemustbe properlyinstalledand groundedbya
qualifiedtechnicianinaccordancewiththeNationalElectrical
CodeANSI/NFPA No. 70-latest edition--and localelectrical
code requirements,
This appliance may be connected by means of permanent
"Hard Wiring" or "Power Supply Cord Kit."
When hard wiring, do not leave excess wire in range
compartment. Excess wire in the range compartment may
not allow the access cover tobe replaced properly, and could
create a potential electrical hazard if wires become pinched.
Connect only asinstructed under'_/IRING INSTRUCTIONS"
in section 4A or 4B. When using flexible conduit or range
cable use flex connector or range cable strain relief.
NOTE: Only usecopper wire inconnectiontoterminal block.
(17ram)
Range Side
%
%
To Next Page
