5
Before you begin, thoroughly familiarize yourself with the control panel and remote
as shown below and all its functions, then follow the symbol for the functions you
desire. The unit can be controlled by the touch pad alone or with the remote.
ELECTRONIC CONTROL
Air Conditioner Features
.devreser sthgir llA.cnI ,stcudorP emoH xulortcelE 9002
Operating Instructions
NOTE
The following instructions represent the Touch Pad, the same instructions can be used for the Remote Control.
:EES LLIW UOY:NO TINU NRUT OT
PRESS ON/OFF BUTTON
DO THIS:
Air Conditioner Features & Operating Instructions
Battery Size: AAA
Warning: Do not mix old and new batteries. Do not mix alkaline,
standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.
NOTE: The unit will run in energy saver(eco) mode
when powered on each time, if last shutdown is in cool
or energy saver(eco) mode. In this mode, the fan will
continue to run for 3 minutes after the compressor shuts off.
The fan then cycles on for 90 seconds at 10 minute intervals
until the room temperature is above the set temperature, at
which time the compressor turns back on.
ADJUSTS
TEMPERATURE
OR TIME
DISPLAYS
TEMPERATURE/TIME
SETS FAN
SPEED
SETS MODE
TURNS UNIT
ON OR OFF
ACTIVATES
TIMER
CHECK FILTER
RESET BUTTON
SLEEP MODE
REMOTE TEMP
SENSING INDICATOR
(some models)
WITH
REMOTE SENSING
STANDARD REMOTE
