Frigidaire FGHS2355PF User Manual

10
CAUTION
Be sure doors are set aside in a secure position where
they cannot fall and cause personal injury, or damage
to the doors or handles.
CAUTION
Drawer is heavy. Use caution when lifting.
DOOR REMOVAL INSTRUCTIONS
Once both doors are in place, ensure they are aligned
with each other and level (Please see the “Installation”
section for more details), and replace the top hinge cover.
Lower Hinge Removal
4 Unscrew the three lower hinge screws and hinge if
necessary.
To reinstall the right door, reverse the above steps.
Removing Freezer Drawer
1 Open freezer drawer.
2 Remove drawer screws on right and left sides (two
screws on each side).
3 Lift drawer up and out to remove.
Installing Freezer Drawer
1 With lower slides pulled out, hang drawer onto
slide brackets ensuring pins on each side are fully
inserted into slots on each side.
6 Tighten four drawer screws.
7 Recheck gasket seal.
8 Installthetoegrillebyttingintoplace.
2 Reinstall four drawer screws (two per side), tighten
down, and close drawer (C).
Push Against
Freezer Drawer
Grab Drawer
At Center
From Both Sides
Then
Pull Drawer Out
A B
Fully Extend
Assembly
Drawer Slides
Pin
Slot
Cabinet
Drawer
Install Screws
(2) Each Side
3 Check gasket seal around top, bottom, and sides of
freezer drawer.
4 If gasket is not sealed, open drawer and slightly
loosen four drawer screws (two on each side) to
allow drawer to rotate.
5 Close drawer and recheck the seal on the gasket
(A). Open the drawer grabbing by the sides in the
center (B). Be careful not to rotate the drawer.

NOTE
Youwillbepullingapproximatelyvefeetofwatertube
from the back of the refrigerator.
Remove Hex
Head Drawer
Screw
Remove Hex
Head Drawer
Screw
Do Not Remove
Other Screws
Do Not Remove
Other Screws
Remove Hex
Head Drawer
Screw
Remove Hex
Head Drawer
Screw

NOTE
Do not remove center screw from freezer drawer. This
is a factory adjustment.

NOTE
When reinserting the water tube and replacing the top
hinge cover, use care to be sure you do not kink the tube.

Frigidaire FGHS2355PF Specifications

General

Type	freestanding
Style	side-by-side
Color	stainless steel
Refrigerator Capacity	22.6 cubic feet
Freezer Capacity	8.4 cubic feet
Humidity Controlled Crispers	yes
Defrost System	automatic
Quick Freeze	no
Number of Refrigerator Door Bins	yes
Temperature Control	digital
Interior Light	led
Ice Maker	yes
Water Filter	yes
Door Alarm	no
Smart Home	no
Annual Energy Consumption	549 kilowatt hours
Voltage	120 volts
Current	15 amperes

Weight and Dimensions

Depth	35.625 inches
Height	69.875 inches
Width	33 inches
Net Weight	287 pounds
