Frigidaire FGHS2355PF User Manual

6
INSTALLATION
Toe Grille Must
Fit in Slot on
Anti-tip Bracket
Screw/Washer
Assembly
(3) Retaining Clips
Most of these conditions can be met by raising or
lowering the adjustable front rollers.
To level the cabinet using the front rollers:
1 Slightly open freezer drawer. Lift the toe grille and
gently pull forward (see illustration).
Leveling Freezer Drawer (if necessary)
To level the freezer drawer:
1 Check gasket seal around top, bottom, and sides of
freezer drawer.
2 If gasket is not sealed, open drawer and slightly
loosen four drawer screws (two on each side) to
allow drawer to rotate.
3 Close drawer and recheck the seal on the gasket
(A). Open the drawer grabbing by the sides in the
center (B). Be careful not to rotate the drawer.
4 Tighten four drawer screws.
5 Recheck gasket seal.
Level Refrigerator & Adjust Doors
(if necessary)
Guidelines for nal positioning of your refrigerator:
• Allfourcornersofthecabinetmustrestrmlyonthe
oor.
• The sides should tilt
1
/
4
inch (6 mm) from front to
back (to ensure that doors close and seal properly).
• Doors should align with each other and be level.
Push Against
Freezer Drawer
Grab Drawer
At Center
From Both Sides
Then
Pull Drawer Out
A B
Raise
Lower
Anti-tip
Leg
Door
Door
2 You can raise or lower each door. Use a 3/8 inch
socket wrench to turn the adjustment screws
(1 per side).
To raise: turn adjustment screw clockwise.
To lower: turn adjustment screw counterclockwise.
3 Ensure both doors are bind-free with their seals
touching the cabinet on all four sides and that
cabinet is stable.
4 After unit is leveled, lower anti-tip leg until it
contactstheoor.
5 Installthetoegrillebyttingintoplace.
Remove Hex
Head Drawer
Screw
Remove Hex
Head Drawer
Screw
Do Not Remove
Other Screws
Do Not Remove
Other Screws
Remove Hex
Head Drawer
Screw
Remove Hex
Head Drawer
Screw

Frigidaire FGHS2355PF Specifications

General

Type	freestanding
Style	side-by-side
Color	stainless steel
Refrigerator Capacity	22.6 cubic feet
Freezer Capacity	8.4 cubic feet
Humidity Controlled Crispers	yes
Defrost System	automatic
Quick Freeze	no
Number of Refrigerator Door Bins	yes
Temperature Control	digital
Interior Light	led
Ice Maker	yes
Water Filter	yes
Door Alarm	no
Smart Home	no
Annual Energy Consumption	549 kilowatt hours
Voltage	120 volts
Current	15 amperes

Weight and Dimensions

Depth	35.625 inches
Height	69.875 inches
Width	33 inches
Net Weight	287 pounds
