5
COOKTOP FEATURES
Read these instructions carefully before using the cooktop
1. Left Rear Induction Element
2. Left Front Induction Element
3. Center Front Induction Element (36” model only)
4. Center Rear (30” model only) or Right Rear Induc-
tion Element (36” model only)
5. Right Front Induction Element
6. Left Front Element Control Knob & Indicator
7. Left Rear Element Control Knob & Indicator
8. Center Front Element Control Knob & Indicator (36”
model only)
9. Center Rear Element Control Knob & Indicator
10. Right Front Element Control Knob & Indicator
CAUTION
The Cooking Zones may appear to be cool while turned
ON and after they have been turned OFF. The glass
surface may be HOT from residual heat transferred
from the cookware and burns may occur.
Figure 1
30" Model
Figure 2
36" Model
1
2
6 8 9 107
3
4
5
1
4
2
6 7 9 10
5
