Frigidaire FPRU19F8RF User Manual

6
INSTALLATION

NOTE
All set screws should be tightened and sub-ush (Allen set screw should be seated just
below the surface of the end cap) of handle end cap. The end caps should be drawn tight to
refrigerator door with no gaps.
Door Handle Mounting Instructions
1. Remove handle from carton and any other protective packaging.
2. Position refrigerator handle end caps over upper and lower pre-installed shoulder bolts (A)
that are fastened into door, ensuring the holes for the set screws are facing towards the
outside of door if a single unit installation or the freezer door (if installing the matching
freezer).
3. While holding handle rmly against door, fasten upper and lower Allen set screws (B) with
supplied Allen wrench.
4. Repeat steps 2 and 3 to install freezer handle (if installing the matching freezer). Ensure
the holes for the set screws are facing towards the refrigerator door.
A
B
Single Unit Installation
A
B
Ensure Handle Set Screws are Facing
Each Other with Doors Closed.
Matching Refrigerator and Freezer Door
Handle Installation
Ensure Handle Set Screws are Facing
Each Other with Doors Closed
Frigidaire Gallery
®
Frigidaire Professional
®
Ensure Handle Set Screws are Facing
Each Other with Doors Closed.

Frigidaire FPRU19F8RF Specifications

General

Child lock	Yes
Door hinge	Right
Control type	Buttons
Product color	Grey, Stainless steel
Housing material	Stainless steel
Reversible doors	No
Appliance placement	Freestanding
Fridge door balconies	7
Number of vegetable drawers	1
Fridge number of shelves/baskets	3
Noise level	- dB
Certification	Star-K, CSA
Climate class	-
Fridge net capacity	526 L
Fridge gross capacity	538 L
Lamp type	LED
Cord length	1.8 m
Current	20 A
Connected load	- W
AC input voltage	115 V
AC input frequency	60 Hz
Annual energy consumption	331 kWh
Package weight	111130 g

Weight and Dimensions

Depth	673.1 mm
Width	812.8 mm
Height	1793 mm
Weight	104326 g
Depth with door open	1450 mm
