CAUTION
Be sure doors are set aside in a secure
position where they cannot fall and
cause personal injury, or damage to the
doors or handles.
9
DOOR REMOVAL
Getting through narrow spaces
If refrigerator will not fit through an
entrance area, you can remove the doors.
Check first by measuring the entrance.
To prepare for removing the doors:
1. Unplug the electrical power cord
from the wall outlet.
2. Remove any food from the door
shelves and close the doors.
To remove the refrigerator doors:
1. Open doors to 90°.
2. Remove all 5 Phillips
TM
screws from
top hinge cover and lift up. You can
easily access 3 Phillips screws. You
can access the other 2 screws by
removing the 2 panels from the top
hinge cover as shown.
5. Pull up on water line gently to
remove from door.
3. Trace lightly around the door’s top
hinges with a pencil. This makes
reinstallation easier.
4. Disconnect any electrical harnesses
running from the doors to the
hinge cover.
6. Remove three 8 mm bolts from both
top hinges. Lift doors up o lower
hinges and carefully set aside.
x2
NOTE
Use care while pulling the water tube
from the door to be sure the tube does
not kink.
NOTE
You will pull approximately 4 ft of water
tube from the refrigerator door.
