- 12 -
5-6 Replacement of stirrer motor
1. Disconnect power and remove grille screws(3).
2. Remove grille and the bracket duct upper screw(1).
3. Remove the bracket duct upper and disconnect the
stirrer motor wire.
4. Remove stirrer motor screws(1) and pull the stirrer
motor.
5-7 Removal of stirrer
The stirrer is motor driver and located on the upper side
of the cavity. The oven uses a top feed wave guide.
The stirrer is located in the wave guide and the motor is
located on the wave guide.
1. Disconnect power and open the door.
2. Remove the clip and turn the stirrer cover left.
3. Remove stirrer cover and the stirrer will come with it.
To Next Page
