General Data - High Delta-T Ceiling Concealed FCU (4 rows coil) 50/60Hz
Note:
1) Nominal cooling capacity is based on the following condition:
a) Water temperature: 5.5°C (inlet) / 14.5°C (outlet)
b) Air entering condition: 27.0°C DB / 19.5°C WB
2) Air volume is tested under entering air condition of 20.0°C DB and dry coil condition.
3) All the units’ airflow value stated is at high speed.
4) Sound pressure level is based on 11.5 dB(A) anechoic room background noise.
5) Extended drain pan is optional upon request
6) The manufacturer reserves the rights to make changes to the above specification without prior notice.
Model FCR 200B 300B 400B 500B 600B 800B 900B 1000B 1200B 1400B
Air Flow
High
CMH 330 610 760 900 1150 1450 1620 2115 2445 2750
CFM 194 359 447 529 676 853 953 1244 1438 1618
Medium
CMH 310 530 710 860 1120 1410 1540 1980 2220 2580
CFM 182 312 418 506 659 829 906 1165 1300 1518
Low
CMH 240 330 500 620 770 1100 1200 1470 1570 1870
CFM 141 194 294 365 453 647 706 865 924 1100
Total Cooling
Capacity
High W 2063 3392 4238 5637 6511 8042 10372 11361 12949 13726
Medium W 2000 3200 4100 5500 6400 7900 10100 11000 12400 13300
Low W 1784 2532 3475 4722 5353 7072 9036 9593 10534 11450
Sensible
Cooling
Capacity
High W 1450 2474 2908 3798 4675 5798 7205 8091 9796 10155
Medium W 1400 2300 2800 3700 4600 5700 7000 7800 9300 9800
Low W 1204 1708 2262 3036 3657 4925 6043 6525 7534 8070
External Static Pressure Pa 75
Filter
Type Washable Type
Material Nylon
Thickness 8mm
Fan
Type Centrifugal Forward Curved Blades
Quantity 1 2 3 4 3
Material Galvanized Steel
Drive Direct-drive
Motor
Type Permanent Split Capacitor with Thermal Overload Protection
Insulation Class Class B
Power Supply
V/Ph
/Hz
220~240/1/50~60
Quantity 1 2
Rated Power Input W 65 95 115 133 190 240 270 370 575 615
Cooling Coil
Type
Seamless Copper Tubes Mechanically Bonded to
Aluminium Hydrophilic Fins and Collars
Max. Working
Pressure
Mpa 2
Pipe
Connection
Mm
(in)
DN20 (3/4") - Female Threaded
Water Flow
Rate
l/s 0.23 0.35 0.43 0.52 0.67 0.83 1.07 1.17 1.32 1.36
Water Pressure
Drop
kPa 14 20 26 13 14 22 27 15 29 18
Net Weight kg 22 26 30 32 34 46 48 51 55 60
Dimension
Length mm 660 880 960 1060 1160 1460 1560 1660 1460 1660
Width mm 553 553 553 553 553 553 553 553 609 609
Height mm 256 256 256 256 256 256 256 256 300 300
Sound Pressure
Level
at ESP: 75 Pa
dB
(A)
46 47 50 50 51 51 53 55 60 61
Condensate Drain Size
mm
(in)
DN20 (3/4") - Male Threaded
