General Data - High Air Volume FCU (4 rows coil) 50/60Hz
Note:
1) Nominal cooling capacity is based on the following condition:
a) Water temperature: 7.0°C (inlet) / 12.0°C (outlet)
b) Air entering condition: 27.0°C DB / 19.5°C WB
2) Air volume is tested under entering air condition of 20.0°C DB and dry coil condition.
3) All the units’ airflow value stated is at high speed.
4) Sound pressure level is based on 11.5 dB(A) anechoic room background noise.
5) Extended drain pan is optional upon request
6) The manufacturer reserves the rights to make changes to the above specification without prior notice.
Model FFM
800BH 1000BH 1200BH 1600BH
High Med Low High Med Low High Med Low High Med Low
Air Flow
High ESP
(H)
CMH 1265 1015 815 1510 1215 970 1925 1540 1230 2490 1990 1595
CFM 744 597 479 888 715 571 1132 906 724 1465 1171 938
Total
Cooling
Capacity
High
ESP
(H)
130
Pa
W 8290 6640 5300 9870 7900 6310 12040 9630 7700 15930 12750 10200
Sensible
Cooling
Capacity
W 6110 4890 3920 7390 5910 4730 8750 6990 5600 11870 9510 7610
External
Static
Pressure
Pa 130
Filter
Type Washable Type
Material Nylon
Thickness 8mm
Fan
Type Centrifugal Forward Curved Blades
Quantity 1 1 1 2
Material Galvanized Steel
Drive Direct-drive
Motor
Type Permanent Split Capacitor with Thermal Overload Protection
Insulation Class Class B
Power
Supply
V/Ph/
Hz
220~240/1/50~60
Quantity 1 1 1 1
Rated
Power
Input
at ESP: 130
Pa
W 280 370 600 700
Cooling
Coil
Type
Seamless Copper Tubes Mechanically Bonded to Aluminium Hydrophilic Fins and
Collars
Pipe
Connection
mm(in) DN25 (1") - Male Threaded
Water Flow
rate
l/s 0.44 0.50 0.66 0.86
Water
Pressure
Drop
kPa 6 14 25 20
Net Weight kg 55 55 61 74
Dimension
Length mm 860 860 960 1110
Width mm 770 770 770 770
Height mm 430 430 430 430
Sound Pressure Level
dB
(A)
58 58 59 61
Condensate Drain Size mm(in) DN25 (1") - Male Threaded
