Page 13
General Data - High Air Volume FCU (4 rows coil) 50/60Hz
Note:
1) Nominal cooling capacity is based on the following condition:
a) Water temperature: 7.0°C (inlet) / 12.0°C (outlet)
b) Air entering condition: 27.0°C DB / 19.5°C WB
2) Air volume is tested under entering air condition of 20.0°C DB and dry coil condition.
3) All the units’ airflow value stated is at high speed.
4) Sound pressure level is based on 11.5 dB(A) anechoic room background noise.
5) Extended drain pan is optional upon request
6) The manufacturer reserves the rights to make changes to the above specification without prior notice.
Model FFM
1800BH 2000BH 3000BH
High Med Low High Med Low High Med Low
Air Flow
High
ESP
(H)
130
Pa
CMH 2945 2360 1890 3880 3100 2485 5500 4395 3520
CFM 1732 1388 1112 2282 1824 1462 3235 2585 2071
Total
Cooling
Capacity
High
ESP
(H)
130
Pa
W 19110 15290 12220 24260
19390
15530 34410 27510 22010
Sensible
Cooling
Capacity
High
ESP
(H)
130
Pa
W 14280 11420 9140 17620
14090
11290 25000 19980 15990
External
Static
Pressure
Pa
130
Filter
Type Washable Type
Material Nylon
Thickness 8 mm
Fan
Type Centrifugal Forward Curved Blades
Quantity 2 2 3
Material Galvanized Steel
Drive Direct-drive
Motor
Type Permanent Split Capacitor with Thermal Overload Protection
Insulation Class Class B
Power Supply
V/Ph
/ Hz
220~240/1/50~60
Quantity (H)/(S) 2 2 3
Rated
Power
Input
at ESP: 130 Pa W 750 1200 1800
Type 220~240/1/50~60
Pipe
Connection
mm(in)
DN25 (1") - Male
Threaded
DN40 (1 1/2") - Male Threaded
Cooling
Coil
Water Flow
rate
l/s 1.01 1.25 1.71
Water
Pressure Drop
kPa 25 35 45
Net Weight kg 93 107 140
Dimension
Length mm 1260 1560 2010
Width mm 770 770 770
Height mm 430 430 430
Sound Pressure Level dB (A) 62 64 66
Condensate Drain Size mm(in) DN25 (1") - Male Threaded
