General Data - Ceiling Cassette FCU 50/60Hz
Note:
1) Nominal cooling capacity is based on the following condition:
a) Water temperature: 7.0°C (inlet) / 12.0°C (outlet)
b) Air entering condition: 27.0°C DB / 19.0°C WB
2) Air volume is tested under entering air condition of 20.0°C DB and dry coil condition.
3) All the units’ airflow value stated is at high speed.
4) Sound pressure level is based on 11.5 dB(A) anechoic room background noise.
5) Unit is equipped with water pump
Model FKM 500A 600A 1000A 1400A
Air Flow
High
CMH 850 1003 1598 2550
CFM 500 590 940 1500
Medium
CMH 731 850 1360 2176
CFM 430 500 800 1280
Low
CMH 595 714 1156 1836
CFM 350 420 680 1080
Total Cooling
Capacity
High W 4500 5700 8220 12900
Fan Type Centrifugal forward curved blades
Fan Motor Type Low Noise 4-Speed
Rated Power Input at ESP: 0 Pa W 76 90 145 225
Cooling Coil
Type
Seamless copper tube mechanically bonded to
aluminum hydrophilic Fin
Pipe Connection mm(in) DN20 (3/4") - Female Threaded
Water Flow Rate l/s 0.22 0.27 0.40 0.62
Water Pressure
Drop
kPa 16.0 23.8 31.2 40.0
Net Weight kg 26 35 38 40
Unit Dimension
Length mm 570 835 835
Width mm 570 835 835
Height mm 260 250 290
Panel Dimension
Length mm 650 950
Width mm 650 950
Height mm 55 55
Sound Pressure
Level
at ESP: 0 Pa dB (A) 45 45 48 50
Condensate Drain Size mm(in) DN20 (3/4")
