14
A482enT2.man
10 EXCHANGE OF WEARING PARTS
All screws screwed in steel are secured with Loctite 222.
10.1 Exchange of tensioning wheel and slide plate.
• Unscrew end cover A48.2213.
• Remove tensioning wheel A48.2211 from the tension shaft.
• Unscrew slide plate A48.1213.
• Reassemble in opposite order (observe the position of the tensioning wheel).
10.2 Exchange of cutter, cutter jack, cutting jaws and notching knives.
• Unscrew cylinder cover A48.2118.
• Remove diaphragm A48.2131.
• Unscrew piston plate A48.2117 by pushing the piston plate against the pressure springs.
• Unscrew cover plate A48.2135.
• Unscrew both cutting jaw guides A48.1133.
• Remove cutting jaw assembly downwards in a diagonal position.
• Exchange cutter A48.2119.
• If in addition the cutter jack A48.2120 has to be replaced,
the cylinder bottom must be removed from the connection plate A48.2121 and the connection plate must
be unscrewed from the tensioning body A48.2201.
• In order to be able to replace the cutting jaws and the notching knives a side plate must be removed from
the cutting jaw assembly.
Reassemble in opposite order.
Do not forget to secure the screws (LOCTITE 222)!
Tighten the screws N1.1128 in the cover plate using a force of 41 Nm!
11 CHART OF TYPES
UNI = Uniflex (Regular Duty max. 850 N/mm
2
/ 123`000 psi)
ULT = Ultraflex (High Tensile max. 1100 N/mm
2
/ 160`000 psi)
Item-No. Model Strap width Strap thickness Strap -
quality
Max. tension Speed
N lbs. mm/s inch/s
13.4610 A482/19/0.63-0.80/ULT/4.0 19 mm / 3/4" 0.63-0.80 mm / .025"-.031" ULT 4000 900 125 4.9
13.4620 A482/19/0.80/ULT/7.0 19 mm / 3/4" 0.80 mm / .031" ULT 7000 1570 70 2.7
13.4630 A482/19/0.70-0.90/UNI/4.0 19 mm / 3/4" 0.70-0.90 mm / .027"-.035" UNI 4000 900 125 4.9
13.4640 A482/19/0.70-0.90/UNI/7.0 19 mm / 3/4" 0.70-0.90 mm / .027"-.035" UNI 7000 1570 70 2.7
