Fromm P318 - Page 23

[ ] = Group * = Wearing parts
23
43083001.een.fm
15 SPARE PARTS LIST 43.0830.01
43.0830.01 P318/13.0/0.35-0.80/PET P318.0001.01 27.10.09
Item-No. in group Pcs. Description Dimension Field
N1.1305 P31.0102 2 SCREW M4 X 7.8 D9
N1.1553 P32.1250 1 HEXAGON SCREW M4 X 8 C12
N1.1904 3 SCREW M5 X 20 C6
N1.1909 P31.0104 2 FLAT HEAD SCREW M3 X 5 D2+
N1.1922 P31.0102 1 SCREW M3 X 10 C17
N1.1927 P31.0109 2 FLAT HEAD SCREW M4 X 60 A19
N1.1929 2 SCREW M5 X 50 D6
N1.1934 P31.0109 3 FLAT HEAD SCREW M4 X 50 A19
N1.1952 P31.0102 4 FLAT HEAD SCREW M4 X 20 A7
N1.1957 1 SCREW M3 X 6 C4
N1.2216 1 COUNTERSUNK SCREW M3 X 8 D3
N1.2216 P32.0172 3 COUNTERSUNK SCREW M3 X 8 B24
N1.3150 P32.1414 1 SOCKET SET SCREW M3 X 8 C24
N1.5120 P32.1414 1 HEXAGON NUT M3 C24
N1.6331 P31.0102 2 SPACER WASHER 6 X 12 X 0.5 C14+
N1.6331 P31.0109 2 SPACER WASHER 6 X 12 X 0.5 B18
N1.6344 P31.0102 1 SPACER PIECE 6.3 X 15 X 5 D14
N1.6503 5 SAFETY WASHER M5 C5
N1.6504 P31.0102 6 SAFETY WASHER M4 B7+
N1.6504 P31.0109 5 SAFETY WASHER M4 B19
N1.6504 P32.1250 1 SAFETY WASHER M4 C12
N1.6505 1 SAFETY WASHER M3 C17
N1.6505 P31.0102 1 SAFETY WASHER M3 C4
N1.6505 P31.0104 2 SAFETY WASHER M3 D2+
N1.7206 P31.1126 1 PT-SCREW 2.2 X 10 C20
N1.7211 P31.0110 6 PT-SCREW 3 X 20 A20
N21.5124 P31.0110 1 PRESSURE SPRING 0.9 X 10 X 15/5.5 D22
N2.1118 P31.0110 1 SECURITY RING 6 C24
N2.1121 1 SECURITY RING 5 C12
N2.1121 P31.0102 4 SECURITY RING 5 D10+
N2.1606 P31.0110 1 SPRING RING SW6 A20
N2.1610 P31.0102 1 SPRING RING SB44 B15
N2.1805 P31.0102 1 TENSIONING RING 6 D14
N2.2110 P31.0105 1 PARALLEL PIN 4 m6 X 10 D8
N2.2118 P31.0102 1 PARALLEL PIN 4 m6 X 14 D14
N2.2119 P32.0140 1 PARALLEL PIN 4 m6 X 18 C16
N2.2122 P32.0140 2 PARALLEL PIN 3 h6 X 14 C16
N2.2166 P31.0106 4 PARALLEL PIN 4 h6 X 20 B15+
N2.2187 P31.0105 1 PARALLEL PIN 3 m6 X 6 C9
N2.2189 P31.0108 4 PARALLEL PIN 3 m6 X 5 D2
N2.2190 P31.0102 1 PARALLEL PIN 6 h6 X 18 B17
N2.2193 1 PARALLEL PIN 3 m6 X 32 C11
N2.2443 P32.0139 1 DOWEL PIN 4 X 15 A8
N2.3342 P31.0102 1 FEATHER KEY 2 X 2 X 10 C1
N2.4902 4 HAMMER HEAD BOLT 1.85 X 4.76 C5+
N2.5153 P31.0110 1 PRESSURE SPRING 0.4 X 4.1 X 16/10.5 C23
N2.5157 P31.0102 2 PRESSURE SPRING 0.6 X 4.8 X 20/15.5 B8
N2.5178 2 PRESSURE SPRING 0.32 X 2.82 X 20.5/
20.5
D11
N2.5237 1 PRESSURE SPRING 0.8 X 4.8 X 25/18.5 C11
N2.5294 P32.0139 1 PRESSURE SPRING 2.5 X 15 X 46.5/9.5 B9
