Fromm P318 - Page 24

[ ] = Group * = Wearing parts
24
43083001.een.fm
N2.5295 P31.0102 1 PRESSURE SPRING 1.5 X 21 X 27/5.5 B9
N2.5296 P31.0102 1 PRESSURE SPRING 0.5 X 4 X 24/16.5 C9
N2.5822 P31.0102 1 TORSION SPRING 1.25 X 12/3.75 D14
N2.5823 1 TORSION SPRING 2.8 X 17/4 C4
N31.1118 P31.0110 2 BALL BEARING 10 X 19 X 5 C22
N31.1120 P31.0110 1 BALL BEARING 4 X 11 X 4 C22
N3.1134 1 BALL BEARING 7 X 22 X 7 B4
N3.1134 P31.0102 1 BALL BEARING 7 X 22 X 7 B16
N3.1134 P32.1021 1 BALL BEARING 7 X 22 X 7 A18
N3.1137 P31.0110 2 BALL BEARING 15 X 24 X 5 B22
N3.1137 P32.0150 1 BALL BEARING 15 X 24 X 5 B24
N3.1157 P31.0106 1 BALL BEARING 30 X 42 X 7 C16
N3.1159 P31.0102 1 BALL BEARING 6 X 19 X 6 B18
N3.1160 P32.0119 1 BALL BEARING 40 X 52 X 7 A14
N3.1172 2 BALL BEARING 30 X 42 X 7 B3+
N3.1178 P31.0107 1 BALL BEARING 35 X 44 X 5 B14
N3.1702 P31.0102 6 BALL 4 MM D10
N3.2105 P31.0106 4 NEEDLE CAGE K 4 X 7 X 7 TN C15+
N3.2347 P32.0144 2 NEEDLE BUSH 10 X 14 X 12 A17
N3.3172 P31.0105 1 SLIDE-BEARING 8 X 10 X 10 C1
N3.3172 P31.0108 3 SLIDE-BEARING 8 X 10 X 10 C2
N3.3174 P32.0139 2 SLIDE-BEARING 4 X 5.5 X 6 A8+
N3.3174 P32.2079 1 SLIDE-BEARING 4 X 5.5 X 6 D23
N3.3174 P32.2080 1 SLIDE-BEARING 4 X 5.5 X 6 C20
N3.4509 P32.0150 1 NEEDLE FREE WHEELING 6 X 10 X 15 A24
N3.4509 P32.0156 1 NEEDLE FREE WHEELING 6 X 10 X 15 D14
N3.4520 P32.0151 1 FREE-WHEELING 6 X 10 X 12 C22
N41.9127 1 ADHESIVE LABEL 20 X 10 X 0.1 B5
N43.9164 1 ADHESIVE LABEL WEEE B20
N43.9189 1 TYPE PLATE <<P318>> A7
N43.9192 P31.0110 2 ADHESIVE LABEL 18 Volt A21+
N4.9159 1 LABEL <<CE>> C5
N51.2194 P31.0110 1 INSERTATION PART D22
N5.2367 P31.1126 1 MICRO SWITCH D21
N5.2368 P31.1126 1 MICRO SWITCH C20
N5.2702 1 COVER B20
N61.6216 P31.0110 3 O-RING 23.5 X 3 B21+
P30.1158 1 GUIDE PIN D11
P30.1164 1 GUIDE PIN D11
[P31.0102] P31.0109 1 BODY A11
[P31.0104] 1 TENSIONING BODY D2
[P31.0105] P31.0102 1 BODY C8
[P31.0106] P31.0102 1 IDLER STEP B15
[P31.0107] P31.0102 1 WHEEL A15
[P31.0108] P31.0104 1 TENSIONING BODY D2
[P31.0109] 1 BASE MODEL A13+
[P31.0110] P31.0109 1 DRIVE C19
P31.1101 P31.0105 1 BODY A1+
P31.1102 P31.0107 1 WHEEL B14
P31.1103 P31.0102 1 LEVER D14
P31.1104 P31.0102 1 CATCH PAWL D14
P31.1105 P31.0108 1 TENSIONING BODY D2
P31.1107
*
1 TENSIONING WHEEL B3
