Fromm P323 - Page 24

[ ] = Group * = Wearing parts
24
43313201.een.fm
[P32.1701] 1 COUPLER C12
P32.1702 P32.1701 1 THRUST PIECE C11
P32.1703 P32.0121 1 TENSIONING BODY C4
P32.1706 1 STEEL INSERT D7
P32.1707
*
1 WELDING STOP GRIPPER D7
P32.1708
*
1 CUTTER C10
P32.1709 1 GUIDE CASE C11
P32.1710 1 CENTERING SLEEVE C11
P32.1712 3 DOWEL B4
P32.1719
*
1 GRIPPER C3
P32.1720
*
1 GRIPPER C3
P32.1721
*
1 GRIPPER C4
P32.1723 1 STRAP STOP D4
P32.1724 1 STRAP GUIDE C4
P32.1726 P32.0129 1 END COVER C5
P32.1727 3 IDLER GEAR B4
P32.1729
*
1 TENSIONING WHEEL B4
[P32.1731] P32.0141 1 WELDING EXCENTRIC D22
P32.1732 P32.1731 1 WELDING EXCENTRIC C22
[P32.1901] P32.0141 1 BODY A2
P32.1902 P32.1901 1 BODY A1+
P32.1903 P32.0141 1 HOOK B17
[P32.1904] P32.0141 1 CIRCUIT BOARD 14.4V C21
P32.1905 P32.0141 1 COVER B7
P32.1906 P32.0143 1 LEVER B7
P32.1907 P32.0141 1 FIXING PLATE A9
[P35.0136] P32.0141 1 ROCKER D22
43.3132.01 P323/19/0.65-1.05 P323.0001.01 08.09.05
Item-No. in group Pcs. Description Dimension Field
