11
P356000101enT1.man
8.4 Sealing the straps
Press down and release immediately the sealing
valve lever.
The plastic strap is welded and cut off from the strap
coil at the same time.
After the expiration of the adjusted sealing time,
the seal has to cool down approx. 2 sec.
During that time, the tool can not be removed from
the sealed strap.
After the expiration of the adjusted cooling time the
welding jaw and the seesaw levers move upwards.
Now the tool can be removed from the strap.
8.5 Removing the tool
Pull up the handle lever,
pull the tool right / backwards and off the strapping.
8.6 Seal - Control
A regular control of the seal is necessary. The seal can be examined visually.
Make a seal, peel it apart and examine it as follows:
Correct seal
The seal must be completely welded over the whole width of the strap
on a length of ca. 19 mm. Minor quantities of fused plastic may
overflow on sides.
Welding time too short
The plastic strap is not welded over the whole width of the strap. The
seal efficiency is insufficient.
Warning! Straps with insufficient seal strength must be removed from
the package!
Adjust the welding time (see 6.3.2).
Welding time too long
If the welding time is too long the straps are overheated. The fused
plastic overflows on both sides of the straps. The seal efficiency is
affected.
Warning! Straps with insufficient seal strength must be removed from
the package!
Adjust the welding time (see 6.3.2).
Seesaw lever
