Fromm P356 - Page 24

[ ] = Group * = Wearing parts
24
49037401.een.f
[P35.0137] P35.0128 2 SPUR WHEEL A17+
[P35.0138] P35.0128 1 PISTON B14
[P35.0139] P35.0128 1 HANDLE HOUSING D19
[P35.0140] P35.0139 1 MOTOR CELL A21
[P35.0141] P35.0139 1 VALVE D20
[P35.0142] P35.0139 1 VALVE HEAD A24+
[P35.0143] 1 TENSIONING BODY D2
[P35.0145] 1 END COVER D4
[P35.0146] 1 COUPLER C18
[P35.0147] 1 SUSPENSION --
[P35.0149] P35.0128 1 WELDING EXCENTRIC B16
P35.1344 P35.0128 1 SLIDE GATE C9
P35.2005 P35.0128 1 EXHAUST RING B15
P35.2008 P35.0128 1 BEARING SUPPORT B17
P35.2009 P35.0128 1 TORSIONAL STOP B16
P35.2022 P35.0131 10 FELT A4+
P35.2022 P35.0140 10 FELT B21
P35.2023 P35.0131 1 END PLATE B5
P35.2023 P35.0140 1 END PLATE A21
P35.2026 P35.0128 1 SPRING B6
P35.2026 P35.0139 1 SPRING A22
P35.2027 P35.0128 1 THRUST PIECE B6
P35.2027 P35.0139 1 THRUST PIECE A22
[P35.2029] P35.0134 1 CONTROL ROD A10
P35.2031 P35.0134 1 END RING A10
P35.2032 P35.0134 1 VALVE SHELL A11
P35.2038 P35.0128 1 CONTROL HEAD B8
P35.2043 P35.0141 1 COUPLER D20
P35.2045 P35.0141 2 SUSTAINING RING C21
P35.2046 P35.0141 1 END RING D21
P35.2055 P35.0142 1 SUSTAINING RING D22
P35.2057 P35.0142 2 THROTTLE SEAT C27
P35.2058 P35.0142 2 THROTTLE BODY C28
P35.2059 P35.0142 2 GUIDE B28
P35.2060 P35.0142 2 THROTTLE SCREW B29
P35.2061 P35.0142 2 THROTTLE HOLDER A29
P35.2062 P35.0142 1 DISK C26
P35.2064 1 HANDLE SHAFT A22
P35.2065 1 AIR CONNECTION C14
P35.2067 P35.0147 1 BOLT --
P35.2068 P35.0147 1 FLANGE --
P35.2069 P35.0147 2 RATCHET DISK --
P35.2073 P35.0147 1 DISK --
[P35.3101] P35.0129 1 BODY A1+
P35.3102 P35.0129 1 SWIVEL SHAFT C2
P35.3103 P35.0130 1 PLANET SHAFT B10
P35.3104 P35.0130 3 IDLER GEAR B9
P35.3105 P35.0130 1 COVER A9
P35.3106 P35.0131 1 ROTOR B4
P35.3107 P35.0131 1 JACKET A4
P35.3107 P35.0140 1 JACKET B21
P35.3108
*
P35.0131 5 VANE B5
P35.3108
*
P35.0140 5 VANE B21
P35.3109 P35.0131 1 END PLATE A3
49.0374.01 P356/19/0.65-1.05 P356.0001.01 09.08.04
Item-No. in group Pcs. Description Dimension Field
