Table of contents
General 4
Safety 4
FCC / RSS Compliance 5
Device concept 6
System Limitations 6
Maximum Distance Between the Rapid Shutdown Box and the PV Array 6
Technical Data 6
Compatibility with Inverters 7
Service code 307 on the SnapInverter series 8
Service Code 1175 on the GEN24 inverter series 8
Triggering a rapid shutdown 9
Performing a reset after a rapid shutdown 9
Installing the Rapid Shutdown Box 10
Drilling pattern 11
Mounting the Rapid Shutdown Box - Duo on a rail 11
Attaching the Rapid Shutdown Box to the wall 12
Connecting the Rapid Shutdown Box 13
Wiring of the Rapid Shutdown Box - Duo 13
Connecting the wires Rapid Shutdown Box - Quattro 14
Connecting a MC4-Y-Connector 15
Connecting several Rapid Shutdown Boxes 15
Connecting the wires to the Terminals 16
Connecting the Rapid Shutdown Box to a SnapINverter 16
Connecting the Rapid Shutdown Box to GEN24 Inverter 17
Connecting the Rapid Shutdown Box Grounding 18
SnapINverter: Connecting the Rapid Shutdown Box to an emergency stop button 19
GEN24 inverter: Connecting the Rapid Shutdown Box to an emergency stop button 20
Connecting the Rapid Shutdown Box to a Fronius Primo 10.0 / 11.4 / 12.5 / 15.0 20
Connecting the Rapid Shutdown Box to a Fronius Primo GEN24 208-240 21
3
EN-US
