Fronius Selectiva 4120 - Menu Selection; Statistics Mode; History Mode

The charger parameters can be set individually. More information can be found in the
"Configuration mode" section.
Menu selection
Change from standard mode to the menu selection as follows:
1
Press and hold the "Menu" key for approx. 5 seconds.
Change from all other modes to the menu selection as follows:
1
Briefly press the "Menu" key.
To select the desired mode:
2
Use the "Up/Down" keys to select the symbol for the desired mode.
- e.g. the battery symbol for standard mode
3
Use the "Pause/Start" key to confirm the "Tick" symbol.
Statistics mode In statistics mode, horizontal bars display
the frequency of the following device oper-
ating statuses:
- Idle
- Charging
- Floatingcharge
- Cooldown
- Error
1
Use the "Up/Down" keys to toggle between page 1/2 and page 2/2.
Page 2/2 shows the following values:
- Total number of charges.
- Total Ah output.
- Average Ah output per charge.
- Total energy consumed (kWh).
- Average energy consumed (kWh) per
charge.
The consumed energy display is a standard value and can deviate from the actual
amount of energy by up to 5% at nominal output. At lower power levels the deviation
may be higher.
History mode History mode provides information about the parameters for all the stored charging pro-
cesses. In order to show changing or different displays, two versions of the display win-
dow are shown below:
