Specifications 1
The purpose of this manual is to assist you
in operating and maintaining your Disc
Harrow. Read it carefully. It furnishes infor-
mation and instructions that will help you
achieve years of dependable performance.
These instructions have been compiled
from field experience and engineering
data. Some information may be general in
nature, due to unknown and varying oper-
ating conditions. However, through expe-
rience and these instructions, you should
be able to develop procedures suitable to
your particular situation.
The illustrations and data used in this
manual were current at the time of print-
ing. However, due to possible inline pro-
duction changes, your machine may vary
slightly in detail. We reserve the right to
redesign and change the machines as
may be necessary without notification.
Throughout this manual, references are
made to right and left direction. These are
determined by standing behind the tractor
facing the direction of forward travel.
GENERAL INFORMATION
SPECIFICATIONS
3-Point Hitch
Working Width
Blade Spacing
Tractor HP (MAX)
Shipping Weight
Approximate
Operating Weight
Number of Blades
Blade Size
Blade Thickness
Blade Type
Frame Tubing
Gang Tubing
Bearing Hanger
Bearing Type
Gang Axle
Front Gang Angles
Rear Gang Angles
Apprx. Assembly Time
Category 1
(iMatch Compatible)
76"
9"
55 HP
935 lbs.
890 lbs.
16
20" diameter
3.5mm(.138)
1. Notched (front) /
Notched (Rear)
2. Smooth (Front) /
Smooth (Rear)
3. Notched (Front) /
Smooth (Rear)
3" square
3" square
High strength 3"
channel steel hangers
with 5/8" bolts and
plate
Self aligning sealed
ball bearing in pillow
block
1 1/8" square
13, 16,19,23
8, 11, 19, 23
15 Min.
Category 1
(iMatch Compatible)
80"
7.5"
55 HP
978 lbs.
942 lbs.
20
20" diameter
3.5mm(.138)
1. Notched (Front) /
Notched (Rear)
2. Smooth (Front) /
Smooth (Rear)
3. Notched (Front) /
Smooth (Rear)
3" square
3" square
High strength 3"
channel steel hangers
with 5/8" bolts and
plate
Self aligning sealed
ball bearing in pillow
block
1 1/8" square
13, 16,19,23
8, 11, 19, 23
15 Min.
DH1276
DH1280
Category 1
(iMatch Compatible)
80"
9" Front, 7.5” Rear
55 HP
969 lbs.
915 lbs.
18
20" diameter
3.5mm(.138)
1. Notched (Front) /
Notched (Rear)
2. Smooth (Front) /
Smooth (Rear)
3. Notched (Front) /
Smooth (Rear)
3" square
3" square
High strength 3"
channel steel hangers
with 5/8" bolts and
plate
Self aligning sealed
ball bearing in pillow
block
1 1/8" square
13, 16,19,23
8, 11, 19, 23
15 Min.
DH1280
Category 1
(iMatch Compatible)
96"
9"
55 HP
1040 lbs.
968 lbs.
20
20" diameter
3.5mm(.138)
1. Notched (Front) /
Notched (Rear)
2. Smooth (Front) /
Smooth (Rear)
3. Notched (Front) /
Smooth (Rear)
3" square
3" square
High strength 3"
channel steel hangers
with 5/8" bolts and
plate
Self aligning sealed
ball bearing in pillow
block
1 1/8" square
13, 16,19,23
8, 11, 19, 23
15 Min.
DH1296
Category 1
(iMatch Compatible)
96"
7.5"
55 HP
1066 lbs.
1038 lbs.
24
20" diameter
3.5mm(.138)
1. Notched (Front) /
Notched (Rear)
2. Smooth (Front) /
Smooth (Rear)
3. Notched (Front) /
Smooth (Rear)
3" square
3" square
High strength 3"
channel steel hangers
with 5/8" bolts and
plate
Self aligning sealed
ball bearing in pillow
block
1 1/8" square
13, 16,19,23
8, 11, 19, 23
15 Min.
DH1296
