Frontier FM1012 User Manual

52 Parts
5WPMAN0183 (Rev. 7/9/2008)
FM1012, FM1015 & FM1017 REAR & WING DECK DRIVES (WALTERSCHEID)
FM1012 Wing Drive FM1015 Wing Drive
REF PART QTY DESCRIPTION
A 5WP44628 - Drive, Compl 2300, 21.7 x 32.6
1 5WP44681 1 Yoke, 1-3/8 - 6 Spline QD
2 5WP38352 1 U-Joint Repair Kit 2400
3 5WP38394 1 Slide Lock Collar Repair Kit
4 5WP40778 2 Screw, Guard Retainer
5 5WP40766 2 Bearing Ring, Guard
6 5WP40777 2 Chain, Guard Anti-Rotation
7 5WP38498 1 Yoke, 1-3/8 - 6 Spline QD
8 5WP38478 1 U-Joint Repair Kit 2300
9 5WP40589 1 Slide Lock Collar Repair Kit
10 5WP44682 1 Yoke & Shaft, Male
11 5WP44693 1 Guard, Outer Half
12 5WP44665 1 Drive, Male Half Complete
13 5WP44683 1 Yoke & Shaft, Female
14 5WP44694 1 Guard, Inner Half
15 5WP44666 1 Drive, Female Half Complete
REF PART QTY DESCRIPTION
A 5WP44629 - Drive, Compl 2300, 26.0 x 41.5
1 5WP44681 1 Yoke, 1-3/8 - 6 Spline QD
2 5WP38352 1 U-Joint Repair Kit 2400
3 5WP38394 1 Slide Lock Collar Repair Kit
4 5WP40778 2 Screw, Guard Retainer
5 5WP40766 2 Bearing Ring, Guard
6 5WP40777 2 Chain, Guard Anti-Rotation
7 5WP38498 1 Yoke, 1-3/8 - 6 Spline QD
8 5WP38478 1 U-Joint Repair Kit 2300
9 5WP40589 1 Slide Lock Collar Repair Kit
10 5WP44684 1 Yoke & Shaft, Male
11 5WP44695 1 Guard, Outer Half
12 5WP44667 1 Drive, Male Half Complete
13 5WP44685 1 Yoke & Shaft, Female
14 5WP44696 1 Guard, Inner Half
15 5WP44668 1 Drive, Female Half Complete
FM1017 Wing Drive All Rear Wing Drives
REF PART QTY DESCRIPTION
A 5WP44630 - Drive, Compl 2300, 28.7 x 47.0
1 5WP44681 1 Yoke, 1-3/8 - 6 Spline QD
2 5WP38352 1 U-Joint Repair Kit 2400
3 5WP38394 1 Slide Lock Collar Repair Kit
4 5WP40778 2 Screw, Guard Retainer
5 5WP40766 2 Bearing Ring, Guard
6 5WP40777 2 Chain, Guard Anti-Rotation
7 5WP38498 1 Yoke, 1-3/8 - 6 Spline QD
8 5WP38478 1 U-Joint Repair Kit 2300
9 5WP40589 1 Slide Lock Collar Repair Kit
10 5WP44686 1 Yoke & Shaft, Male
11 5WP44697 1 Guard, Outer Half
12 5WP44669 1 Drive, Male Half Complete
13 5WP44687 1 Yoke & Shaft, Female
14 5WP44698 1 Guard, Inner Half
15 5WP44670 1 Drive, Female Half Complete
REF PART QTY DESCRIPTION
A 5WP44627 - Drive, Compl 2300, 26.8 x 43.3
1 5WP38498 1 Yoke, 1-3/8 - 6 Spline QD
2 5WP38478 1 U-Joint Repair Kit 2300
3 5WP40589 1 Slide Lock Collar Repair Kit
4 5WP40778 2 Screw, Guard Retainer
5 5WP40766 2 Bearing Ring, Guard
6 5WP40777 2 Chain, Guard Anti-Rotation
7 5WP38498 1 Yoke, 1-3/8 - 6 Spline QD
8 5WP38478 1 U-Joint Repair Kit 2300
9 5WP40589 1 Slide Lock Collar Repair Kit
10 5WP44679 1 Yoke & Shaft, Male
11 5WP44691 1 Guard, Outer Half
12 5WP44663 1 Drive, Male Half Complete
13 5WP44680 1 Yoke & Shaft, Female
14 5WP44692 1 Guard, Inner Half
15 5WP44664 1 Drive, Female Half Complete
