Instruction Manual
BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT
1
11
be documented and kept as outlined under OSHA recordkeeping regulations.
No user or employee shall perform work without the proper training and
understanding on how to properly and safely use this product.
The Frontline Bull Ring Roof Anchors are designed for a number of applications
such as fall arrest, fall restraint and work positioning. The anchors can be
installed onto applicable structural wood trusses. The Frontline Bull Ring
Roof Anchor is an active fall protection system that meets all of the design
requirements or applicable standards set forth by OSHA 1926, 1910 and ANSI
Z359.
DESCRIPTION
FIGURE 1 - FRONTLINE FALL ARREST ANCHORS
TOP
Welded Steel Bar with 5K lbs Rated O
-
Ring
9 mm 3/8”
2.5 lbs
BASE THICKNESS
WEIGHT
USER CAPACITY:
SYSTEM SPECIFICATIONS:
SERVICE TEMPERATURE:
BREAKING STRENGTH:
MATERIAL:
1 Person with a combined weight (clothing, tools, etc.) of
no more than: 310 lbs for ANSI.
-30°F to +130°F Minimum Service Temperatures
5,000 lbs Minimum Breaking Strength
Base: ASTM A36 Rated Steel
O
-
Ring: Galvanized Steel
Finishing: Galvanized
FASTENERS:
(5) 1/4” x 3” Steel hex head lag screws
