• Safety labels/markings/tags that are legible with appropriate OSHA/ANSI
markings, product limitations, user capacity and other markings as required
by OSHA/ANSI.
• Defects or any imperfections on the products such as; Corrosion, broken, bent,
deformed, excessive wear, defects in welded areas or any other evidence of
damage or alterations affecting the safety functionality of the anchor.
• Any other conditions that may question the integrity of the anchor, shall be
put out of service.
• Any product that has been subject to a fall or an impact, shall be put out of
service.
• Clean/clear product of any surface contamination such as concrete, stucco,
roofing material or other material that may impact the safe use of the product.
These are minimum requirements, and all inspections should be documented for
recordkeeping. Any questions regarding the safety inspection of Frontline Fall
Protection products please contact us at info@frontlinefall.com.
INSTALLATION
ROOF TRUSS INSTALLATION
When installing onto wood substrates, Frontline requires that the wooden
substrate be of a roof truss structural member and a minimum of 3.5” thick.
Ensure that the wooden substrate is free from any defects including cracks,
decay, rot or any other imperfection. The substrate also must withstand the
required 5,000 lbs minimum breaking strength and approved before use by a
qualified person. Thereafter, then follow the next steps:
1. Identify anchor location and make sure is clean and free of obstructions.
2. Place anchor in upright position and centered on wooden truss member to
allow for all screws or nails to be fully embedded on truss:
a. Screw Installation: Use (5) ¼” x 3” steel hex head lag screws and fully
embed all screws into the substrate as shown on Figure 5.
b. Nail Installation: Use (6) 16d nails and fully embed all nails into the
substrate as shown on Figure 6.
3. Qualified person to inspect and approve installation before using anchor.
4. Once correctly installed and inspected, anchor is ready for use with the
compatible additional PFAS.
