Instruction Manual
BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT
10
be documented and kept as outlined under OSHA recordkeeping regulations.
No user or employee shall perform work without the proper training and
understanding on how to properly and safely use this product.
The Frontline Vertical/Horizontal Beam Anchor is a fixed I-beam anchor that is
easy to operate and designed to clamp onto a vertical or horizontal I-beam to
create a fixed anchor point.
DESCRIPTION
This Anchorage Connector has been tested for compliance with the requirements
of ANSI/ASSE Z359.18-2017. Testing covers only the Anchorage Connector and
does not extend to the connector, body harness, subsystem and/or substrate to
which the Anchorage Connector is attached to.
Prior to installation and use of this equipment, record the product identification
information from the label in the Inspection and Maintenance Log at the end of
this manual. Use a pen or fine point sharpie with blue or black ink when logging
inspections.
APPLICATION
Part
Number
Flange Width
Ranging
Max. Flange
Thickness
ST18AH
ST12AH
Desription
Anchor
Weight
D-ring
Nylon
Bushing
Adjustable
Beam Clamps
Locking
Nut
Safety Pin
Safety Pin
Hex Bar
Double Locking
mechanism
Horizontal Beam Anchor
Horizontal Beam Anchor
3
1/2
”-18”
3
1/2
”-12”
2”
2”
5.64 lbs
4.81 lbs
