Instruction Manual
BUILT TO LAST | MANUFACTURED TO COMPLY | DESIGNED TO PROTECT
18
• Safety labels/markings/tags that are legible with appropriate OSHA/ANSI
markings, product limitations, user capacity and other markings as required
by OSHA/ANSI.
• Defects or any imperfections on the products such as; Corrosion, broken, bent,
deformed, excessive wear, defects in welded areas or any other evidence of
damage or alterations affecting the safety functionality of the anchor.
• Any other conditions that may question the integrity of the anchor, shall be
put out of service.
• Any product that has been subject to a fall or an impact, shall be put out of
service.
• Clean/clear product of any surface contamination such as concrete, stucco,
roofing material or other material that may impact the safe use of the product.
These are minimum requirements, and all inspections should be documented for
recordkeeping. Any questions regarding the safety inspection of Frontline Fall
Protection products please contact us at info@frontlinefall.com.
INSTALLATION
When installing the beam anchor onto structural steel or I
-
Beams, Frontline
requires that I
-
Beam has a minimum flange width of 3.5” and maximum of 12” or
18” depending on the beam anchor being used and an overall thickness of ½” – 2”.
The substrate also must withstand the required 5,000 lbs minimum breaking
strength and approved before use by a qualified person. Thereafter, then follow
the next steps:
1. Make sure that the I-beam is clear of obstructions and that the I-beam is fully
installed and part of the structure.
2. Ideally the beam anchor would be preferred to be used in overhead
applications, if foot level tie-off is required other connecting devices need to be
suitable for the application.
3. Only use the beam anchor on horizontal I
-
Beam applications, not vertical
applications.
4. Once the desired I-beam anchoring location is determined, then loosen both
the outer and inner retainer nuts adjacent to opening the beam anchor, creating
an opening large enough to allow the beam flange to fit between the beam
clamps as shown on figure 5.
