12
115G
Revised: September 1, 2006
PARTS LIST
ID # PART # DESCRIPTION ID # PART # DESCRIPTION
1a COMPLETE DOOR – 115G
FREEZER DOOR GASKET 24 E676-10 ¼” 90° ELBOW
1c E110-07 LIGHT COVER 25 E680-10 MANUAL SHUT OFF VALVE
2 E176-07 EXTERIOR DRAIN PLUG 26 E681-10 MANUAL SHUT OFF VALVE COUPLER
3 E403-07 COOLING UNIT – LPG 27 E685-07 PRESSURE TEST POINT FITTING
4 E476-07NR DISPERSION PLATE –
NARROW
28 E686-07 PRESSURE TEST POINT NUT
4 E476-07WD DISPERSION PLATE – WIDE 29 E700-10 PIEZO IGNITOR
5 E480-07 DISPERSION PLATE
PROTECTOR
30 E704-VF IGNITOR CABLE
6a E527-07 HINGE 31 E708-10 ¼” STRAIGHT METAL FITTING
6b E528-07 PLASTIC HINGE COVER
7 E547-07 BOILER PROTECTOR 34 E720-10 PROPANE HOSE – 3’
8 E546-07 PLATE UNDER BURNER 35 E726-07 PROPANE THERMOSTAT
9 E594-07 METAL BACK 36 E729-07 THERMOMETER
10 E595-07 LEFT SIDE 37 E731-10 BLACK CONTROL BUTTON
11 E596-07 RIGHT SIDE 38 E736-07 THERMOSTAT BRACKET
13 E601-10 HOSE CONNECTOR – MALE 40 E750-10 FLAME INDICATOR
14 E602-10 HOSE CONNECTOR – FEMALE 44 E758-10 ORIFICE HOLDER
15a ¼” NUT FOR STRAIGHT
FITTING
45 E759-10 BURNER NUT
15b 6mm NUT 41b E761-VF GAS BURNER
16b E614-07 ¼” GAS RECEIVING TUBE HIGH ALTITUDE BURNER
17b E621-VF GAS VALVE 42b E766-VF ORIFICE – 0.34mm
18 E625-07 THERMOCOUPLE
CONNECTOR
HIGH ALTITUDE ORIFICE
19b E630-VF THERMOCOUPLE BRASS
TUBE
43 E770-07 FLUE TUBE BAFFLE – LPG
21a E652-10 ¼” BURNER GAS TUBE 53 E790-10 INDICATOR CABLE CONNECTOR
21b E649-07 6mm BURNER GAS TUBE 54 E805-10 GLIDERS
23a E672-10 ¼” STANDARD SLEEVE 55 E850-10 SINGLE CABLE HOLDER
23b E670-10 6mm OVAL DOUBLE CONE 57 E945-07 CONTROL PANEL
