InstructionManualforFrSkyX8RReceiver
Introduction
ThankyouforpurchasingFrSkyX8R8/16chfullduplextelemetryreceiver.Inordertofullyenjoythebenefitsofthis
system,pleasereadtheinstructionmanualcarefullyandsetupthedeviceasdescribedbelow.
Overview

Specifications
Dimension:46.3x26.8x13.6mm(LxWxH)
Weight:14g
NumberofChannels:1~8chfromconventionalchanneloutputs,1~16chfromSBUSport
WithRSSIoutput:analogvoltageoutput(0~3.3V)
OperatingVoltageRange:3.0~10V
OperatingCurrent:100mA
OperatingRange:fullrange(>1.5km)
Compatibility:FrSkyXJTmoduleinD16mode
(Switch1isOFF,Switch2isOFF)orD8mode(Switch1isOFF,Switch2is
ON),DFT/DJT/DHT/DHTͲUinD_mode
FirmwareUpgradeable
What’sNew!
x Morenumberofchannels:1~8chfromconventionalchanneloutputs,1~16chfromSBUSport
x WithRSSIoutput:analogvoltageoutput(0~3.3V)
x SmartPortenabled,realizingtwoͲwayfullduplextransmission.






BindingProcedure
Bindingistheprocessofuniquelyassociatingaparticularreceivertoatransmittermodule.Atransmittermodulecanbe
boundtomultiplereceivers(nottobeusedsimultaneously).Areceivercanonlybeboundtoonetransmittermodule.

SmartPort(S.Port)isasignalwirefullduplexdigitaltransmissioninterfacedevelopedbyFrSkyElectronic
Co.,Ltd.AllproductsenabledwithSmartPort(includingXJTmodule,X8Rreceiver,newhubͲlesssensors,newSmart
Dashboard,etc),serialportuserdataandotheruserinput/outputdevicescanbeconnectedwithoutlimitationsfor
numbersorse
q
uencesatahi
g
htransmissions
p
eed.
