Example 1 – Basic System
Example 2 – DISEqC switches
Example 3 – Combined with terrestrial
Example 4 – Motorized system
QUICK INSTALLATION GUIDE
FOLLOW NEXT STEPS FOR THE CORRECT INSTALLATION OF THIS RECEIVER.
STEP 1: CONNECTIONS
The coaxial cable, with satellite signal, must be connected to the “IF IN” connector. The “TV SCART”
connector must be connector to the TV set.
Depending on the type of installation, the receiver should be connected and confi gured following next
examples.
